1

290881527

BLOCK-SHORT787

1

290887233

CRANKCASE-ASSY

2

290240328

SCREW-HEX.FLAN

3

290941333

SCREW-HEX.FLAN

4

290932797

BEARING-BALL

5

290837350

SHAFT-ROTARY

6

290930580

SEAL-OIL

7

290932032

BEARING-BALL

8

290227439

SHIM

9

290845450

RING-SNAP

10

290847287

SLEEVE-DISTANC

11

293300024

RING-O

12

290935735

SPROCKET-14 TEETH

13

290938810

SPRING

14

290827430

SEAT-SPRING

15

290845160

CIRCLIP-#12

16

290845260

RING-SNAP

17

290922245

TUBE-ANGULAR

18

290810740

COVER-BEARING

19

290230300

RING-O

20

290945823

COVER-BEARING

21

290845382

WASHER-LOCK

22

290240073

SCREW-ALLEN

23

293250042

GASKET

24

293800007

LOCTITE-515

25

290924502

VALVE-ROTARY

26

290831765

RING-O

27

290810738

COVER-ROTARY

28

293800038

LOCTITE-518

29

413707000

DOW CORNING 111

30

290886390

SET-GASKET
