1

270500285

CARBURATOR-PTO

2

270500097

SPRING

6

270500011

WASHER-SPRING

7

270500012

NUT

8

270500222

RING-SEALING

9

270500104

RING-O

10

270500175

JET-PILOT 70

11

270500209

JET-MAIN 142.5

12

270500091

SPRING

13

270500136

WASHER

14

270500228

SCREW

15

270500229

NUT

16

270500230

WASHER-SPRING

17

270500234

RING-SEALING

20

270500239

RING

22

270500115

FILTER-FUEL

23

270500127

RING-O

24

270500241

VALVE-NEEDLE

25

270500129

CLIP

26

270500128

LEVER-VALVE

27

270500267

SPRING

28

270500132

DIAPHRAGM-ASSY

29

270500133

COVER

30

270500131

GASKET

31

270500144

RING-O

32

270500113

SCREW-ADJUSTER

33

270500020

SCREW-IDLE

34

270500019

SPRING

35

270500018

WASHER

36

270500119

RING-O

37

270500155

SCREW-SPR.WASH

38

270500125

PLATE

39

270500038

PIN

40

270500124

VALVE-ASSY.

41

270500123

SCREW

42

270500243

SCREW

43

270500190

SCREW

45

270500271

LEVER-CHOKE AS

46

270500248

SPRING

47

270500110

RING

48

270500154

CAP-WHITE

49

270500221

RING

50

270500192

RING

56

270500138

COVER-PUMP

57

270500109

SCREW

60

270500272

LEVER-THROTTLE

61

270500287

LEVER-THROT.AS

62

270500286

BRACKET

63

270500256

ROD-LINK CARB.

64

293550010

GREASE-SYNTH

65

215987560

SCREW-SOCKET HD.DIN.912A2

66

290845382

WASHER-LOCK

67

293800015

LOCTITE-242

68

413703400

LOCTITE-222

69

293850018

CLIP
