見出番号
部品番号
部品名
数量
1
420950770
CYLINDER HEAD GASKET
2
420613978
HEAD-CYLINDER
3
420929650
PIN-DRIVE 5X10
4
420641323
SCREW
5
420924720
HOSE NIPPLE
6
420253929
VALVE GUIDE
7a
420254682
EXHAUST VALVE
7b
420254293
INTAKE VALVE
8
420630200
VALVE STEM SEAL
9
420238180
VALVE SPRING
10
420838280
VALVE SPRING INSIDE
11
420254281
VALVE SPRING RETAINER
12
420253645
VALVE COTTER
13
420837851
CAMSHAFT
14
420851693
CAMSHAFT GUIDE
15
420254307
TIMING GEAR 38 TEETH
16
420840031
ALLEN SCREW M6
17
420898042
CAMSHAFT CHAIN
18
420236540
CHAIN TENSION GUIDE
19
420236500
CHAIN GUIDE
20
420660037
COVER
21
420627494
THRUST WASHER
22
420856500
VENT VALVE
23
420630125
V-RING
24
420950870
O-RING
25
420641238
SCREW-TORX FLANGE
26
420254329
ROCKER ARM EXHAUST
27
420254316
ROCKERARM ASSY INLET
28
420854594
ROCKER-ARM SHAFT
29
420641080
30
420641110
TORX-RED. SHAFT SCREW M11X147
31
32
420851751
SPARK PLUG PIPE
33
420950820
VALVE COVER GASKET
34
420811587
VALVE COVER
35
420440560
SCREW-TORX
36
420641488
37
420660167
VALVE COVER ORNAMENT
38
707000246
PLUG-SPARK
39
420664020
【品番変更296000307】IGNITION COIL
40
420222425
TEMPERATURE SENSOR
41
420664042
CAMSHAFT SENSOR
42
420641048
TORX FLANGE SCREW
43
420851618
TRANSPORT BRACKET PTO
44
45
420673291
MANIFOLD
46
420641198
47
420851614
TRANSPORT BRACKET FRONT
48
49
420660090
RUBBER BRACKET
50
420460830
SEALING CUP
B
293800060
LOCTITE-243
K
413707000
DOW CORNING 111
W
293550021
GREASE-ISOFLEX
