見出番号
部品番号
部品名
数量
1
275500665
TANK-FUEL
2
250100062
SPECIAL NUT
3
293830094
PAD-RUBBER
4
293730011
DART-BLACK
5
293850067
STRAP-FUEL TANK
6
293850038
STRAP
7
293850066
CLIP-STRAP
8
293150043
RIVET-POP 3/16
9
275500648
HOSE-FIL NECK
10
293650023
CLAMP-TRIDON
11
275500231
NECK-FILLER
12
293250029
GASKET
13
211100012
NUT-NECK FILLER FUEL
14
275500710
CAP-FUEL
16
293250075
17
275500518
CHAIN-CAP FUEL
18
234032600
WASHER-FLAT DIN.9021B-A2
19
390407900
RIVET-POP 1/8
20
241141660
SCREW-PT.HEX.FLANGE K40 X 16
21
270600101
FUEL PUMP
22
270600103
LEVER-SENSOR
23
270600108
FUEL FILTER
24
293250173
25
275500549
HOSE-1/4 (10M/PAC)
26
293650170
HOSE CLAMP
27
293650025
CLAMP-OETIKER
28
293710059
FITTING-Y
29
30
31
275500398
VALVE-CHECK
32
293720029
GROMMET
33
34
35
513033469
36
37
414115200
TIE-RAP 180MM
38
39
293730040
DART-MOUNT
40
275500626
HOSE-5/16
41
275500700
QUICK ATTACH
42
293650011
43
293710105
FITTING-ELBOW
44
293750002
TIE-RAP 130MM
45
46
