1

275500653

2

275500616

C RING 9 STUD

3

389804300

PUSH-NUT

4

292001065

PAD-FOAM

5

293830087

PAD-RUBBER

6

293730006

DART-BLACK

7

293850067

STRAP-FUEL TANK

8

293850024

CLIP-STRAP

9

293850076

CLIP-STRAP 90

10

293850037

STRAP-FUEL TANK

11

293850038

STRAP

12

293850024

CLIP-STRAP

13

293150037

RIVET-AVDEL 3/16

14

275500649

HOSE-FIL NECK

15

293650023

CLAMP-TRIDON

16

275500231

NECK-FILLER

17

293250029

GASKET

18

211100012

NUT-NECK FILLER FUEL

19

275500430

CAP-FUEL SUB

20

293000034

CAP-SNAP BLACK

21

293250075

GASKET

22

275500518

CHAIN-CAP FUEL

23

241140060

SCREW-PT.HEX.FLANGE K40 X 10

24

234032600

WASHER-FLAT DIN.9021B-A2

25

390407900

RIVET-POP 1/8

26

275500610

FUEL MODULE

27

270600051

LEVER-SENSOR

28

275500624

PUMP-MODULE

29

219700368

BOSCH SERVICE FILTER

30

293250088

GASKET

31

250100071

NUT-FLANGE HEXAGONAL M5

32

293800060

LOCTITE-243

33

291001956

RUBBER WASHER

34

275500549

HOSE-1/4 (10M/PAC)

35

293650170

HOSE CLAMP

36

293650050

CLAMP-CLIC

37

293710059

FITTING-Y

38

275500549

HOSE-1/4 (10M/PAC)

39

293650050

CLAMP-CLIC

40

275500398

VALVE-CHECK

41

570135100

GROMMET

42

275500549

HOSE-1/4 (10M/PAC)

43

293650050

CLAMP-CLIC

44

414580600

CONNECTOR-MALE

45

275500549

HOSE-1/4 (10M/PAC)

46

293650050

CLAMP-CLIC

47

275500505

VALVE-CHECK

48

293720029

GROMMET

49

270600007

RAIL-FUEL ASSY

50

207562560

SCREW-HEX.FLANGE DIN.6921 S.GR

51

270600096

CIRCLIP

52

270600095

INJECTOR

53

293300042

RING-O

54

270600009

CAP

55

275500626

HOSE-5/16

56

275500428

CONNECTOR-BOX

57

293650011

CLAMP-OETIKER

58

293710067

FITTING-QUICK

59

275500429

CONNECTOR-STOPPER

60

275500441

RAIL-PROTECTOR

61

293730018

DART-MOUNT
