見出番号 |
部品番号 |
部品名 |
数量 |
1 |
270000573 |
|
|
2 |
707000031 |
ADAP-ASSY
|
|
3 |
270000137 |
HOUSING-TAB
|
|
4 |
270000138 |
ADAP-ASSY
|
|
5 |
293300033 |
GASKET
|
|
6 |
293200055 |
GASKET
|
|
7 |
293710066 |
CONNECTOR-MALE
|
|
8 |
278000987 |
STARTER-ASSY.
|
|
9 |
273000123 |
SUPP.SILENC
|
|
10 |
205063560 |
SCREW-SOCKET HD.DIN.912A2
|
|
11 |
234061600 |
WASHER-FLAT DIN125A-A2
|
|
12 |
234161601 |
WASHER-LOCK HELICAL DIN.127B-A
|
|
13 |
278001662 |
PLATE-GROUND
|
|
14 |
293700016 |
FITTING-ELBOW
|
|
15 |
293710082 |
FITTING-STRAIGHT
|
|
16 |
205003060 |
SCREW-SOCKET HD.DIN.912A2
|
|
17 |
232001600 |
NUT-HEXAGONAL DIN.934A2
|
|
18 |
293800013 |
SEALANT-PIPE
|
|
19 |
293550010 |
GREASE-SYNTH
|
|
20 |
293800005 |
LOCTITE-271
|
|
21 |
207184060 |
SCREW-HEX.CAP DIN.933A2
|
|
22 |
293800060 |
LOCTITE-243
|
|
23 |
234081600 |
WASHER-FLAT DIN.125A-A2
|
|
24 |
270000122 |
SHIM- 0-3MM
|
|
24 |
270000123 |
SHIM- 1-3MM
|
|
25 |
205582560 |
SCREW-SOCKET
|
|
26 |
234081600 |
WASHER-FLAT DIN.125A-A2
|
|
27 |
270000453 |
BUSHING
|
|
28 |
270000421 |
MOUNT-RUBBER
|
|
29 |
234082600 |
WASHER-FLAT DIN.9021B-A2
|
|
30 |
207181660 |
SCREW-HEX.CAP DIN.933A2
|
|
31 |
270000515 |
SUPPORT-ENGINE
|
|
32 |
207182060 |
SCREW-HEX.CAP DIN.933A2
|
|
33 |
234082600 |
WASHER-FLAT DIN.9021B-A2
|
|
34 |
270000025 |
SHIM- 1-3MM
|
|
34 |
270000024 |
SHIM- 0-4MM
|
|
35 |
270000430 |
MOUNT-RUBBER PAINT
|
|
36 |
207184060 |
SCREW-HEX.CAP DIN.933A2
|
|
37 |
234081600 |
WASHER-FLAT DIN.125A-A2
|
|
38 |
270000122 |
SHIM- 0-3MM
|
|
38 |
270000123 |
SHIM- 1-3MM
|
|
39 |
278001650 |
PLUG-SPARK ZFR-4F-11
|
|
40 |
278001016 |
SENSOR-LIQUID
|
|
41 |
293800038 |
LOCTITE-518
|
|
42 |
270600040 |
SENSOR-PRESS.
|
|
43 |
270600019 |
ADAPTOR-VALVE
|
|
44 |
243041660 |
SCREW-PLASTITE HEX.UNSL
|
|
45 |
211200035 |
WASHER-FLAT
|
|
46 |
270600000 |
SENSOR-AIR
|
|
47 |
270000484 |
SENSOR-NOISE
|
|
48 |
207183060 |
SCREW-HEX.CAP DIN.933A2
|
|
49 |
414115200 |
TIE-RAP 180MM
|
|
50 |
293730018 |
DART-MOUNT
|
|
51 |
270600058 |
THROTTLE BODY TWIN BORE
|
|
52 |
270600069 |
SUPPORT-LOWER
|
|
53 |
270600070 |
SUPPORT-ASS Y
|
|
54 |
270600073 |
BRACKET-LATCH
|
|
55 |
205051060 |
SCREW-SOCKET HD.DIN.912A2
|
|
56 |
270600074 |
ADJUSTER-SCREW
|
|
57 |
270600075 |
SPRING
|
|
58 |
270600076 |
BODY-THROTTLE
|
|
59 |
270600077 |
LEVER-THROT.AS
|
|
60 |
270600078 |
SCREW-POTENTIOMETER M4
|
|
61 |
234161601 |
WASHER-LOCK HELICAL DIN.127B-A
|
|
62 |
232061600 |
NUT-HEXAGONAL DIN.934A2
|
|
63 |
270600079 |
SPRING-GUIDE
|
|
64 |
270600080 |
SPRING
|
|
65 |
270000251 |
SENSOR-THROTTL
|
|
66 |
270000544 |
O-RING
|
|
67 |
270600081 |
BODY-THROTTLE
|
|
68 |
270600082 |
LEVER-PICK-UP
|
|
69 |
270600078 |
SCREW-POTENTIOMETER M4
|
|
70 |
234161601 |
WASHER-LOCK HELICAL DIN.127B-A
|
|
71 |
232061600 |
NUT-HEXAGONAL DIN.934A2
|
|
72 |
270600079 |
SPRING-GUIDE
|
|
73 |
270600083 |
SPRING
|
|
74 |
270000251 |
SENSOR-THROTTL
|
|
75 |
270000544 |
O-RING
|
|
76 |
270600084 |
IDLE-SCREW
|
|
77 |
270600085 |
COVER
|
|
78 |
270000546 |
CABLE-INJECT
|
|
79 |
232160600 |
NUT-JAM HEXAGONAL DIN.439B-A2
|
|
80 |
234061600 |
WASHER-FLAT DIN125A-A2
|
|
81 |
277001197 |
THROTTLE CABLE
|
|
82 |
277000279 |
LOCK-TAB
|
|
83 |
293250065 |
RING-O
|
|
84 |
278001512 |
INSULATOR
|
|
85 |
293650079 |
CLAMP-NORMA
|
|
86 |
278000631 |
TERMINAL-MALE
|
|
87 |
293550004 |
GREASE-DIELECT DC4
|
|
88 |
278000735 |
WEDGE-6 WAYS FEMALE
|
|
