見出番号
部品番号
部品名
数量
1
275500581
TANK-FUEL XP-DI
2
293830087
PAD-RUBBER
3
293730006
DART-BLACK
4
292000939
HEAT SHIELD
5
293850036
STRAP-FUEL TANK
6
293830064
STOPPER-RUBBER
7
293850076
CLIP-STRAP 90
8
293850038
STRAP
9
293150037
RIVET-AVDEL 3/16
10
275500584
FILLER HOSE
11
293650023
CLAMP-TRIDON
12
275500229
NECK-FILLER
13
275500589
FUEL SHIELD
14
211100012
NUT-NECK FILLER FUEL
15
275500430
CAP-FUEL SUB
16
293000034
CAP-SNAP BLACK
17
293250017
GASKET
18
275500507
CHAIN-CAP FUEL
19
241140060
SCREW-PT.HEX.FLANGE K40 X 10
20
234032600
WASHER-FLAT DIN.9021B-A2
21
390407900
RIVET-POP 1/8
22
275500585
FUEL MODULE
25
293650140
CLAMP-OETIKER 162
26
293250088
27
233151600
NUT-FLANGE HEXAGONAL DIN.6923-A2
28
293800060
LOCTITE-243
29
291001956
RUBBER WASHER
30
275500549
HOSE-1/4 (10M/PAC)
31
293650128
HOSE CLAMP
32
293650050
CLAMP-CLIC
33
293710059
FITTING-Y
34
275500398
VALVE-CHECK
35
570135100
GROMMET
36
414580600
CONNECTOR-MALE
37
275500505
38
293720029
39
293750008
TIE-RAP 350MM
40
270600051
LEVER-SENSOR
41
275500600
DISTRIBUTOR-FUEL
42
275500460
INJECTOR-FUEL
43
275500543
PLATE-RETAINNER
44
275500538
ADAPTER-AIR
45
293300069
RING-O
46
275500595
FUEL PLUG
47
275500463
REGULATOR-AIR
48
275500456
49
275500596
RETAINER PLATE
50
275500464
REGULATOR-FUEL
51
275500449
COVER
52
293300072
53
275500465
SPACER
54
205051260
SCREW-SOCKET HD.DIN.912A2
55
205061260
56
275500597
AIR PLUG
57
275500598
O-RING
58
275500455
59
270600022
HOSE-PRESSURE
60
293300070
61
275500593
HOSE-ASS Y
62
275500594
63
293300083
64
275500545
INJECTOR-AIR
65
293300084
66
270600030
RING-INJECTOR
67
293300076
68
207087060
SCREW-HEX.CAP DIN.931A2
69
70
234081600
WASHER-FLAT DIN.125A-A2
71
234181601
WASHER-LOCK HELICAL
72
232561600
NUT-STOP ELASTIC DIN.985-A2
73
276000084
HOSE-8MM.(3M/PAC)
74
75
270000569
NOISE REDUCER
76
293830027
WASHER-SEAL
77
293800041
PRIMER-LOCTITE
78
79
211100020
NUT-SPECIAL M27
80
296000309
SEAL-SILICONE
81
291001399
TIE-CLAMP
82
219700368
BOSCH SERVICE FILTER
