1

420888814

CYLINDER BLOCK & SLEEVES

2

420632010

PIN-CENTER

3

420956775

OIL SPRAY NOZZLE

4

420250015

ALUMINUM WASHER

5

420841923

PLUG SCREW M12

6

420641120

TORX-RED SHAFT SCREW M11X147

7

420641203

TORX FLANGE SCREW

8

420641313

PLUG SCREW M30

9

420641170

PLUG SCREW M30

10

420631300

O-RING

11

420249073

GROOVED PIN

12

420430405

O-RING

13

420660110

PLUG COVER

14

420811790

ENGINE BRACKET FRONT

15

420641188

TORX FLANGE SCREW

16

420811785

ENGINE BRACKET PTO EXH.

17

420641188

TORX FLANGE SCREW

18

420641213

TORX FLANGE SCREW

19

420811780

ENGINE BRACKET PTO INL.

20

420851740

RETAINING PLATE

21

420641213

TORX FLANGE SCREW

22

420660290

HOSE BRACKET

23

420236252

CHAIN TENSIONER

24

420430623

GASKET RING A

25

420640453

PLUG SCREW M16

26

420847970

SPACER

27

420660090

RUBBER BRACKET

28

420827968

WASHER M6

29

420641258

SCREW TORX FLANGE M6 X 35

30

420256777

OIL PRESSURE SWITCH

31

420664030

KNOCK SENSOR

32

420641188

TORX FLANGE SCREW

33

420888850

OIL RADIATOR

34

420250055

O-RING

35

420641048

TORX FLANGE SCREW

36

420922796

FORMED HOSE

37

420922791

FORMED HOSE

38

420851663

【品番変更・価格改正→509000442】

39

420851673

GEAR CLAMP

40

420888994

ELECTRIC STARTER ASSY

41

420631310

O-RING

42

420664710

CARBON BRUSH SET

43

420834521

STARTER GEAR 9T

44

420845600

RING-RETAINING

45

420641238

SCREW-TORX FLANGE

46

420232480

BUSHING-NEEDLE

47

420889870

FRICTION CLUTCH

48

420888982

BENDIX STARTER

49

420238300

SPRING-DISK

50

420827261

WASHER-THRUST

51

420956943

OIL LEVEL TUBE

52

420950810

O-RING

53

420956932

OIL LEVEL GAUGE

54

420889770

SET-GASKET 1503

55

293800060

LOCTITE-243

56

413707000

DOW CORNING 111

57

219700346

4 STROKE OIL 10W-40

58

293800081

LOCTITE-5910

59

293550021

GREASE-ISOFLEX

61

415150315
