1

420811840

OIL PUMP HOUSING

2

420837542

PUMP SHAFT ASSY

3

420956675

OUTER ROTOR 16MM

4

420811850

OIL PUMP COVER

5

420641048

TORX FLANGE SCREW

6

420950970

GASKET

7

420641238

SCREW-TORX FLANGE

8

420811892

OIL SIEVE COVER

9

420630240

SEAL RING

10

420950850

GASKET

11

420256570

SIEVE-OIL

12

420641228

TORX FLANGE SCREW

13

420641238

SCREW-TORX FLANGE

14

420641238

SCREW-TORX FLANGE

15

420630231

GASKET

16

420956761

OIL SEPARATOR HOUSING

17

420256885

OIL PRESSURE SWITCH

18

420811962

OIL SEPARATOR COVER

19

420641313

PLUG SCREW M30

20

420956661

SHUT OFF SOLENOID

21

420630540

GASKET

22

420939250

COMPRESSION SPRING

23

420856055

VALVE DISC

24

420845620

RETAINING RING

25

420641048

TORX FLANGE SCREW

26

420630220

GASKET

27

420641238

SCREW-TORX FLANGE

28

420956923

PLUG COVER ASSEMBLY YELLOW

29

420660620

RETAINING BAND

30

420660090

RUBBER BRACKET

31

420847970

SPACER

32

420827968

WASHER M6

33

420641258

SCREW TORX FLANGE M6 X 35

34

420851610

TRANSPORT BRACKET FRONT

35

420641048

TORX FLANGE SCREW

36

420956970

FORM HOSE

37

420851673

GEAR CLAMP

38

420851663

【品番変更・価格改正→509000442】

39

420641323

SCREW

40

293800060

LOCTITE-243

41

219700346

4 STROKE OIL 10W-40
