見出番号
部品番号
部品名
数量
1
293150011
RIVET-POP 3/16
2
293850030
CLIP-STRAP
3
204060017
4
274000222
OUTLET-EXHAUST
5
274000224
NUT-72MM
6
274000225
WASHER-STABILIZING
7
293250041
GASKET
8
296000309
SEAL-SILICONE
9
293850024
10
293830055
PAD-RUBBER
11
293730006
DART-BLACK
12
204060190
FOAM SUPPORT-LOWER
13
270000522
ENGINE-947
14
270000359
SUPPORT-ENGINE
15
205582560
SCREW-SOCKET
16
234081600
WASHER-FLAT DIN.125A-A2
17
270000421
MOUNT-RUBBER
18
207181660
SCREW-HEX.CAP DIN.933A2
19
234082600
WASHER-FLAT DIN.9021B-A2
20
293800060
LOCTITE-243
21
207184060
22
23
270000122
SHIM- 0-3MM
270000123
SHIM- 1-3MM
24
270000422
25
207182060
26
270000024
SHIM- 0-4MM
27
270000025
28
29
30
204250048
204250049
SHIM-1.3MM.
31
293730018
DART-MOUNT
32
414115200
TIE-RAP 180MM
33
271000110
TRIM-PROTECT.(1M/PAC)
34
274000658
CONE-EXHAUST
35
274000511
RING-SEALING
36
413710300
SEALANT
37
274000510
CLAMP-EXHAUST
38
275000007
HOSE-8MM.(10M/PAC)
39
290931990
40
250300008
STUD-M10X55
41
211200051
WASHER-FLAT
42
274000862
ENV-PICK UP
43
293750002
TIE-RAP 130MM
44
233101600
NUT-FLANGE HEXAGONAL
45
205503560
SCREW-SOCKET DIN.912A2 S.GRIP
46
274000662
SUPP-PIPE
47
250000051
48
250200012
WASHER-FLAT M8.4
49
207004060
SCREW-HEX.CAP DIN.931A2
50
293800005
LOCTITE-271
51
234002600
52
234101601
WASHER-LOCK HELICAL
53
274000861
BUSHING
54
293830065
BUSHING-RUBBER
55
274000878
56
205004060
SCREW-SOCKET HD.DIN.912A2
57
274000749
MUFFLER-NOIR
58
274000796
COVER-MUFFLER
59
274000799
60
293750020
TIE-RAP 838MM
61
293850021
STRAP-RUBBER
62
274000530
HOSE-EXHAUST
63
293650064
CLAMP-TRIDON
64
274000616
65
66
295500683
KIT-RESONATOR (GTX-L)
67
274000711
68
274000655
RESONATOR-LH.
69
274000766
ADAP-HOSE
