1

420888812

ENGINE BLOCK ASSY.

2

420632010

PIN-CENTER

3

420956775

OIL SPRAY NOZZLE

4

420430623

GASKET RING A

5

420240233

PLUG SCREW M16

6

420250015

ALUMINUM WASHER

7

420841923

PLUG SCREW M12

8

420641120

TORX-RED SHAFT SCREW M11X147

9

420641203

TORX FLANGE SCREW

10

420641170

PLUG SCREW M30

11

420631300

O-RING

12

420249073

GROOVED PIN

13

420430405

O-RING

14

420660110

PLUG COVER

15

420811790

ENGINE BRACKET FRONT

16

420641188

TORX FLANGE SCREW

17

420811785

ENGINE BRACKET PTO EXH.

18

420641188

TORX FLANGE SCREW

19

420641213

TORX FLANGE SCREW

20

420811780

ENGINE BRACKET PTO INL.

21

420851740

RETAINING PLATE

22

420641213

TORX FLANGE SCREW

23

420660290

HOSE BRACKET

24

420236252

CHAIN TENSIONER

25

420430623

GASKET RING A

26

420640453

PLUG SCREW M16

27

420847970

SPACER

28

420660090

RUBBER BRACKET

29

420827968

WASHER M6

30

420641258

SCREW TORX FLANGE M6 X 35

31

420256777

OIL PRESSURE SWITCH

32

420664030

KNOCK SENSOR

33

420641188

TORX FLANGE SCREW

34

420888850

OIL RADIATOR

35

420250055

O-RING

36

420641048

TORX FLANGE SCREW

37

420922796

FORMED HOSE

38

420922791

FORMED HOSE

39

420851663

【品番変更・価格改正→509000442】

40

420851673

GEAR CLAMP

41

420888994

ELECTRIC STARTER ASSY

42

420631310

O-RING

43

420664710

CARBON BRUSH SET

44

420834521

STARTER GEAR 9T

45

420845600

RING-RETAINING

46

420641238

SCREW-TORX FLANGE

47

420232480

BUSHING-NEEDLE

48

420889870

FRICTION CLUTCH

49

420890632

BENDIX STARTER

50

420238300

SPRING-DISK

51

420827261

WASHER-THRUST

52

420956943

OIL LEVEL TUBE

53

420950810

O-RING

54

420956932

OIL LEVEL GAUGE

55

420889770

SET-GASKET 1503

56

293800060

LOCTITE-243

57

413707000

DOW CORNING 111

58

293600039

OIL 4T 12X1 BLEND QUART

59

293800081

LOCTITE-5910

60

293550021

GREASE-ISOFLEX

61

415150315
