見出番号
部品番号
部品名
数量
1
233101600
NUT-FLANGE HEXAGONAL
2
211200051
WASHER-FLAT
3
274000714
PIPE-HEAD
4
207004060
SCREW-HEX.CAP DIN.931A2
5
274000656
BUSHING
6
293830065
BUSHING-RUBBER
7
293150037
RIVET-AVDEL 3/16
8
270000462
ENGINE-947
9
270000359
SUPPORT-ENGINE
10
274000543
TUBE-EXP.
11
234081600
WASHER-FLAT DIN.125A-A2
12
13
274000224
NUT-72MM
14
270000122
SHIM- 0-3MM
270000123
SHIM- 1-3MMShim
15
414644300
DART-WINDSHIELD
16
270000421
MOUNT-RUBBER
17
234002600
WASHER-FLAT DIN.9021B-A2
18
207181660
SCREW-HEX.CAP DIN.933A2
19
207184060
20
274000225
WASHER-STABILIZING
21
205582560
SCREW-SOCKET
22
274000783
HOSE-EXHAUST
23
293650064
CLAMP-TRIDON
24
293830074
PAD-RUBBER
25
293850026
STRAP-FUEL TANK
26
293850024
CLIP-STRAP
27
274000787
MUFFLER-NOIR
28
293250041
GASKET
29
274000530
30
293800033
SEAL-SILICONE
31
274000505
OUTLET-EXHAUST
32
293800015
LOCTITE-242
33
205003560
SCREW-SOCKET HD.DIN.912A2
34
205004060
35
36
37
274000510
CLAMP-EXHAUST
38
274000511
RING-SEALING
39
413710300
SEALANT
40
275000007
HOSE-8MM.(10M/PAC)
41
234101601
WASHER-LOCK HELICAL
42
234082600
43
211300025
STUD-M10X55
44
293800005
LOCTITE-271
45
274000662
SUPP-PIPE
46
47
48
293250080
49
50
51
270000430
MOUNT-RUBBER PAINT
52
270000024
SHIM- 0-4MM
53
270000025
SHIM- 1-3MM
54
207182060
55
293050001
WASHER-8MM
56
293830073
PAD RESONATOR
57
293730006
DART-BLACK
58
274000666
59
293800038
LOCTITE-518
60
293850045
CLIP-STRAP 90
61
292000628
PAD-FOAM
62
293730018
DART-MOUNT
63
294000606
TIE-RAP 180MM
64
274000658
CONE-EXHAUST
65
274000740
COVER-MUFFLER
66
274000741
67
293650092
CLAMP-NORMA
68
274000700
RESONATOR-LH.
69
274000784
HOSE-ADAPTER
70
204000079
