1

212200004

SCREW-PAN HD.PH.DIN.7985A-A2

2

213200010

WASHER-FLAT DIN.433A2

3

275500299

KNOB-VALV.FUEL

4

212100009

NUT-HEX.PLASTIC

5

293710046

FITTING-STRAIG

6

275500400

VALVE-FUEL

7

212000001

NUT-STOP ELASTIC DIN.985-A2(M6

8

210100014

SCREW-SET SOCKET DIN.916A2

9

293250004

GASKET

10

293650023

CLAMP-TRIDON

11

275500139

HOSE-6MM.(4.572M/PAC)

12

293550004

GREASE-DIELECT DC4

13

293650038

HOSE CLAMP

14

275500270

HOSE-FORMED

15

275500358

FILTER-FUEL ASSY.

16

275500089

FILTER-FUEL

17

275500090

RING-O

18

293850023

STRAP-FUEL TANK

19

275500109

TANK-FUEL

20

275500404

BAFFLE-PICK UP ASSY.

21

275500111

ADAP-TUBE FUEL

22

275500397

FILTER-FUEL

23

293650042

CLAMP-OETIKER

24

213200018

WASHER-FLAT DIN.9021B-A2

25

390407900

RIVET-POP 1/8

26

275500104

VALVE-CHECK

27

293830033

PAD-RUBBER

28

293730006

DART-BLACK

29

293650035

CLAMP-TRIDON

30

275500110

HOSE-FIL.NECK

31

293250029

GASKET

32

275500231

NECK-FILLER

33

275500168

CHAIN-CAP FUEL

34

211000028

SCREW-PT.HEX.FLANGE K40 X 10

35

293250075

GASKET

36

211100012

NUT-NECK FILLER FUEL

37

275500153

CAP-FUEL SUB.

38

293000034

CAP-SNAP BLACK

39

275500398

VALVE-CHECK

40

293710001

FITTING-ELBOW

41

293720029

GROMMET

42

293850024

CLIP-STRAP

43

293150037

RIVET-AVDEL 3/16

44

293750002

TIE-RAP 130MM

45

275500241

PLUG-CAP FUEL VALVE

46

293710059

FITTING-Y

47

293710024

FITTING-T

48

294000606

TIE-RAP 180MM

49

293830011

WASHER-RUBBER

50

270000281

CABLE-CHOKE

51

291000457

PLATE-CHOKE

52

212100003

NUT-JAM HEXAGONAL DIN.439B-A2

53

213200001

WASHER-FLAT DIN.125A-A2(M6)

54

211100030

NUT-HEXAGONAL HI-LEX

55

293750005

TIE-CLAMP

56

275500113

SUPP-FILTER FU

57

275500285

PLATE-VAL.FUEL

58

275500345

HOSE-5/16

59

293650047

CLAMP-OETIKER
