1

290094702

SHORT BLOCK 947

1

290887754

CRANKCASE-ASSY

2

290941333

SCREW-HEX.FLAN

3

290940638

SCREW-HEX.FLAN

4

290632010

PIN-CENTER

5

290232480

BUSHING-NEEDLE

6

420950141

RING-SEALING

7

290440193

SCREW-ALLEN

8

290230300

RING-O

9

290811200

COVER-BEARING

10

290924602

VALVE-REED ASS

11

290924612

REED-PEDAL

12

290924617

STOP-REED PEDAL

13

420941215

SCREW-OVAL HEAD M3X5

14

290867833

ADAP-CARB.

15

420956510

VALVE-CHECK

16

413707000

DOW CORNING 111

17

290888040

DRIVE-STARTER

18

290938204

SPRING

19

290811210

COVER-DRIVE ST

20

290845020

WASHER-SPRING

21

290840401

SCREW-ALLEN

22

290953330

SUPPORT-WIRE

23

413711400

LOCTITE-648

24

293800015

LOCTITE-242

25

293800038

LOCTITE-518

26

290240033

SCREW-HEX.FLANGE DIN.6921

27

290888131

SET-GASKET

28

293250066

GASKET
