1

290094702

SHORT BLOCK 947

1

290887762

CRANKSHAFT-ASS

2

420246055

KEY-WOODRUFF

3

420432271

BEARING-BALL 947CRANK

4

290926190

WASHER

5

290931731

SEAL-OIL

6

290837387

SHAFT-BAL.ASSY

10

290932098

BEARING-BALL

11

420927192

WASHER

12

290232555

BEARING-NEEDLE

13

290916395

PISTON PIN

14

290845465

CIRCLIP-#21

15

290887775

PISTON-ASSY

15

290887776

PISTON-ASSY.
Piston

16

290815175

RING-L

16

290815176

RING-L
Semi-Trapez

17

290815190

RING-R

17

290815191

RING-L
Semi-Trapez

18

290841663

SCREW-ALLENDER

19

290832550

NEEDLE BEARING

20

290827782

WASHER

21

290640120

SCREW-HEX.

22

290958130

FLANGE-COUPLING

23

290499113

FITTING-GREASE

24

293800015

LOCTITE-242

25

413711400

LOCTITE-648

26

413707000

DOW CORNING 111

27

290958086

COUPLING-SILVER

28

290888131

SET-GASKET

29

290888136

SET-GASKET CYL
