見出番号 |
部品番号 |
部品名 |
数量 |
1 |
211100052 |
NUT-FLANGE HEXAGONAL DIN.6923-
|
|
2 |
211200051 |
WASHER-FLAT
|
|
3 |
274000657 |
PIPE-HEAD
|
|
4 |
215604060 |
SCREW-HEX.CAP DIN.931A2
|
|
5 |
274000254 |
BUSHING
|
|
6 |
293830036 |
BUSHING-RUBBER
|
|
7 |
293150037 |
RIVET-AVDEL 3/16
|
|
8 |
270000368 |
ENGINE-947
|
|
9 |
270000359 |
SUPPORT-ENGINE
|
|
10 |
210000002 |
SCREW-HEX.CAP DIN.933A2
|
|
11 |
213000001 |
WASHER-LOCK HELICAL DIN.127B-
|
|
12 |
213200002 |
WASHER-FLAT DIN.125A-A2(M8)
|
|
13 |
274000224 |
NUT-72MM
|
|
14 |
270000122 |
SHIM- 0-3MM
|
|
14 |
270000123 |
SHIM- 1-3MM
Shim
|
|
15 |
293730011 |
DART-BLACK
|
|
16 |
270000352 |
MOUNT-RUBBER
|
|
17 |
217002600 |
WASHER-FLAT DIN.9021B-A2
|
|
18 |
215681660 |
SCREW-HEX.CAP DIN.933A2
|
|
19 |
215084060 |
SCREW-HEX.CAP DIN.933A2
|
|
20 |
293850024 |
CLIP-STRAP
|
|
21 |
211000178 |
SCREW-SOCKET DIN.912A2 S.GRIP
|
|
22 |
274000707 |
HOSE-EXHAUST
|
|
23 |
293650064 |
CLAMP-TRIDON
|
|
24 |
293830055 |
PAD-RUBBER
|
|
25 |
293850021 |
STRAP-RUBBER
|
|
26 |
274000225 |
WASHER-STABILIZING
|
|
27 |
274000599 |
MUFFLER-SILVER REFL.
|
|
28 |
293250041 |
GASKET
|
|
29 |
274000530 |
HOSE-EXHAUST
|
|
30 |
293800033 |
SEAL-SILICONE
|
|
31 |
274000222 |
OUTLET-EXHAUST
|
|
32 |
293800015 |
LOCTITE-242
|
|
33 |
215903560 |
SCREW-SOCKET HD.DIN.912A2
|
|
34 |
215904060 |
SCREW-SOCKET HD.DIN.912A2
|
|
35 |
293650064 |
CLAMP-TRIDON
|
|
36 |
274000658 |
CONE-EXHAUST
|
|
37 |
274000510 |
CLAMP-EXHAUST
|
|
38 |
274000511 |
RING-SEALING
|
|
39 |
413710300 |
SEALANT
|
|
40 |
275000007 |
HOSE-8MM.(10M/PAC)
|
|
41 |
213000003 |
WASHER-LOCK HELICAL DIN.127B-A
|
|
42 |
213200011 |
WASHER-FLAT DIN.9021B-A2
|
|
43 |
211300025 |
STUD-M10X55
|
|
44 |
293800005 |
LOCTITE-271
|
|
45 |
274000679 |
SUPP-PIPE
|
|
46 |
211000178 |
SCREW-SOCKET DIN.912A2 S.GRIP
|
|
47 |
215084060 |
SCREW-HEX.CAP DIN.933A2
|
|
48 |
293250080 |
GASKET
|
|
49 |
213200002 |
WASHER-FLAT DIN.125A-A2(M8)
|
|
50 |
270000122 |
SHIM- 0-3MM
|
|
50 |
270000123 |
SHIM- 1-3MM
Shim
|
|
51 |
270000353 |
MOUNT-RUBBER
|
|
52 |
270000024 |
SHIM- 0-4MM
|
|
53 |
270000025 |
SHIM- 1-3MM
|
|
54 |
210000001 |
SCREW-HEX.CAP DIN.933A2
|
|
55 |
293050001 |
WASHER-8MM
|
|
56 |
274000616 |
HOSE-EXHAUST
|
|
57 |
295500683 |
KIT-RESONATOR (GTX-L)
|
|
58 |
274000636 |
SUPPORT-PIPE
|
|
59 |
293800038 |
LOCTITE-518
|
|
