1

212200004

SCREW-PAN HD.PH.DIN.7985A-A2
Countersunk

2

213200010

WASHER-FLAT DIN.433A2
Washer

3

275500299

KNOB-VALV.FUEL
Fuel

4

212100009

NUT-HEX.PLASTIC
Nut

5

275500241

PLUG-CAP FUEL VALVE
Plug

6

275500098

VALVE-FUEL
Fuel

7

212000001

NUT-STOP ELASTIC DIN.985-A2(M6
Elastic

8

293650042

CLAMP-OETIKER
Oetiker

9

293250004

GASKET
Valve

10

293650035

CLAMP-TRIDON
Tridon

11

275500139

HOSE-6MM.(4.572M/PAC)
Hose

12

293250005

GASKET
Gasket.

13

293650038

HOSE CLAMP
Tridon

14

293750005

TIE-CLAMP
Tie-Clamp.

15

275500088

FILTER-FUEL AS
Fuel

16

275500089

FILTER-FUEL
Fuel

17

275500090

RING-O
O-Ring.

18

293650038

HOSE CLAMP
Tridon

19

275500183

TANK-FUEL
Fuel

20

275500318

BAFFLE-PICK UP
Baffle

21

275500111

ADAP-TUBE FUEL
Tube

22

275500249

FILTER-FUEL
Fuel

23

275500316

HOSE-FIL.NECK
Filler

24

213200018

WASHER-FLAT DIN.9021B-A2
Washer

25

293150032

RIVET-POP 1/8
Rivet

26

275500104

VALVE-CHECK
Pressure

27

293830033

PAD-RUBBER
Pad

28

293730006

DART-BLACK
Dart

29

293650023

CLAMP-TRIDON
Tridon

30

275500211

HOSE-FIL.NECK
Filler

31

293250029

GASKET
Gasket.

32

275500247

NECK-FILLER
Filler

33

275500015

CHAIN-CAP OIL
Chain.

34

211000028

SCREW-PT.HEX.FLANGE K40 X 10
Screw.

35

293250017

GASKET
Gasket.

36

211100012

NUT-NECK FILLER FUEL
Nut

37

275500194

CAP-FUEL SUB.
Fuel

38

293000015

CAP-SNAP VIOL.
Snap

39

275500087

VALVE-CHECK
Check

40

293710001

FITTING-ELBOW
Elbow

41

293720029

GROMMET
Grommet.

42

293850024

CLIP-STRAP
Strap

43

293150037

RIVET-AVDEL 3/16
Rivet

44

293750008

TIE-RAP 350MM
Tie

45

570135100

GROMMET
Grommet.

46

293710039

FITTING-STRAIG
Straight

47

293710024

FITTING-T
<>

48

294000606

TIE-RAP 180MM
Tie

49

210100014

SCREW-SET SOCKET DIN.916A2
Socket

50

270000295

CABLE-CHOKE
Choke

51

291000457

PLATE-CHOKE

52

211100030

NUT-HEXAGONAL HI-LEX

53

212100003

NUT-JAM HEXAGONAL DIN.439B-A2

54

211100007

NUT-HEXAGONAL HI-LEX

55

293850025

STRAP-FUEL TANK

56

293850026

STRAP-FUEL TANK
