見出番号
部品番号
部品名
数量
1
275000081
CAP-OIL ASSY.
2
293250025
RING-O
3
275000064
NECK-FILLER
4
211100013
NUT-NECK FILLER OIL
5
293650038
HOSE CLAMP
6
293250016
GASKET
7
293650035
CLAMP-TRIDON
8
275000070
HOSE-FIL.NECK
9
275000015
TANK-OIL
10
293720002
GROMMET
11
570135100
12
293710002
FITTING-ELBOW
14
293710001
15
275000051
FILTER-OIL
16
275000007
HOSE-8MM.(10M/PAC)
17
275000008
HOSE-12MM
18
275500018
HOSE-6MM.(30M/PAC)
19
275500087
VALVE-CHECK
20
293850022
STRAP-OIL TANK
21
293750001
TIE-RAP 94MM
22
293750005
TIE-CLAMP
23
293710003
24
293650042
CLAMP-OETIKER
