1

275500437

HOSE-ASSY

1

204000068

HOSE-1/4INC (1.524M/PAC)

2

275500428

CONNECTOR-BOX

3

293650053

CLAMP-OETIKER

4

293300042

RING-O

5

293800060

LOCTITE-243

6

270600010

CIRCLIP

7

207562560

SCREW-HEX.FLANGE DIN.6921 S.GR

8

270600008

RAIL-FUEL

9

270600009

CAP

10

293650023

CLAMP-TRIDON

11

275500139

HOSE-6MM.(4.572M/PAC)

12

270600029

MODULE-FUEL PUMP/REWORK

13

270600012

LEVEL-SENSOR

14

293730018

DART-MOUNT

17

293250088

GASKET

18

293850037

STRAP-FUEL TANK

19

293850024

CLIP-STRAP

20

234052400

WASHER-FLAT DIN.7349

21

275500416

VALVE-CHECK

22

232551200

NUT-STOP ELASTIC DIN.985

23

293650042

CLAMP-OETIKER

24

275500441

RAIL-PROTECTOR

25

275500429

CONNECTOR-STOPPER

26

293650038

HOSE CLAMP

27

293830077

PAD-RUBBER

28

270600017

INJECTOR

29

293300071

RING-O

30

275500377

HOSE-FIL.NECK

31

293250029

GASKET

32

275500231

NECK-FILLER

33

293710039

FITTING-STRAIG

34

293720029

GROMMET

35

293250075

GASKET

36

211100012

NUT-NECK FILLER FUEL

37

275500430

CAP-FUEL SUB

38

293000034

CAP-SNAP BLACK

39

275500398

VALVE-CHECK

40

293850036

STRAP-FUEL TANK

41

293850024

CLIP-STRAP

42

275500427

TANK-FUEL

43

293150037

RIVET-AVDEL 3/16

44

293710059

FITTING-Y

45

293550004

GREASE-DIELECT DC4

46

293730006

DART-BLACK

47

275500352

TUBE-SPACER

48

293250071

GASKET

49

270600020

BODY-THROTTLE

50

270000251

SENSOR-THROTTL

51

211000205

SCREW-POTENTIOMETER M4

52

205063060

SCREW-SOCKET HD.DIN.912A2

53

205569060

SCREW-SOCKET DIN.912A2 S.GRIP

54

232160600

NUT-JAM HEXAGONAL DIN.439B-A2

55

219700368

BOSCH SERVICE FILTER
