1

290094703

SHORT BLOCK 947

1

290931902

CYLINDER GASKET 0.8MM

1

290931901

CYLINDER GASKET 0.6MM
Gasket

1

290931900

GASKET-CYL.
Gasket

2

290613561

CYLINDER-ASSY.

3

290632010

PIN-CENTER

4

290931702

GASKET-CYL.HE.

5

290923921

CYLINDER-HEAD ASSY

6

290640232

STUD-M10X200

7

290842863

NUT-STUD M10

8

290841708

SCREW-HEX.FLAN

9

290854410

VALVE-EXHAUST

10

290931765

RING-O

11

290931670

GASKET-RUBBER

12

290854435

HOUSING-RAVE

13

205062560

SCREW-SOCKET HD.DIN.912A2

14

290931765

RING-O

15

290926220

RING-SUPPORT

16

290838260

SPRING-COMPRES

17

290260723

BELLOWS

18

290239048

SPRING-HOSE

19

290854446

VALVE-EXHAUST

20

290939137

SPRING-RAVE

21

290911558

COVER-VALVE

22

420241220

SCREW-ADJUSTER

23

420838083

SPRING CLAMP　(2PCS/PACK)

24

420931653

EXHAUST MANIFOLD GASKET

25

290979606

EXHAUST MANIFOLD SILVER

26

290931990

GASKET

27

234101601

WASHER-LOCK HELICAL

28

290941483

SCREW-SOCKET

29

205006060

SCREW-SOCKET HD.DIN.912A2

30

290889150

SET-GASKET

31

290889155

SET-GASKET CYL

32

293800060

LOCTITE-243

33

413707000

DOW CORNING 111

34

290850460

RING-O

35

420838253

CLAMP-SPRING

36

293800038

LOCTITE-518

37

234000600

WASHER-FLAT DIN.433A2
