見出番号 |
部品番号 |
部品名 |
数量 |
1 |
290887767 |
CRANKSHAFT-ASS
|
|
2 |
420246055 |
KEY-WOODRUFF
|
|
3 |
420432271 |
BEARING-BALL 947CRANK
|
|
4 |
420926190 |
WASHER 947CRANKSHAFT
|
|
5 |
290931731 |
SEAL-OIL
|
|
6 |
290837445 |
SHAFT-BAL.ASSY
|
|
10 |
290932097 |
BEARING-BALL
|
|
11 |
420927192 |
WASHER
|
|
12 |
290232555 |
BEARING-NEEDLE
|
|
13 |
290932096 |
BALL BEARING
|
|
14 |
290818955 |
MASS-BALANCE
|
|
15 |
290889045 |
PISTON-ASSY
|
|
15 |
290889040 |
PISTON-ASSY.
Piston,
|
|
15 |
290889046 |
PISTON-ASSY
Piston
|
|
15 |
290889043 |
PISTON-ASSY
Piston
|
|
16 |
290815267 |
RING-R
|
|
16 |
290815265 |
RING-R
Rectangular
|
|
16 |
290815268 |
RING-R
Rectangular
|
|
16 |
290815266 |
RING-R
Rectangular
|
|
17 |
293550010 |
GREASE-SYNTH
|
|
18 |
205082060 |
SCREW-SOCKET HD.DIN.912A2
|
|
19 |
290832552 |
NEEDLE BEARING
|
|
20 |
290827782 |
WASHER
|
|
21 |
290640120 |
SCREW-HEX.
|
|
22 |
290958122 |
FLANGE-COUPLING
|
|
23 |
290499113 |
FITTING-GREASE
|
|
24 |
293800060 |
LOCTITE-243
|
|
25 |
413711400 |
LOCTITE-648
|
|
26 |
413707000 |
DOW CORNING 111
|
|
27 |
290958082 |
COUPLING-SILVER
|
|
28 |
413802900 |
OIL 2T 12X1 MINERAL
|
|
29 |
290916398 |
PISTON PIN
|
|
29 |
290916396 |
PISTON PIN
Piston
|
|
30 |
290845465 |
CIRCLIP-#21
|
|
31 |
290921460 |
PIN-COMPRESSOR
|
|
32 |
290640690 |
SCREW-M6X25
|
|
33 |
290917505 |
CONROD-ASSY
|
|
34 |
290916430 |
PIN-PISTON
|
|
35 |
290847940 |
BUSH-DISTANCE
|
|
36 |
290888550 |
PISTON-ASSY
|
|
37 |
290215970 |
RING-RECTANGULAR
|
|
38 |
290215960 |
RING-SCRAPER OIL
|
|
39 |
290094706 |
BLOCK-SHORT947
|
|
39 |
290094705 |
BLOCK-SHORT947
Short
|
|
40 |
290888134 |
SET-GASKET
|
|
41 |
290888139 |
SET-GASKET CYL
|
|
|
