見出番号
部品番号
部品名
数量
1
207087060
SCREW-HEX.CAP DIN.931A2
2
293800060
LOCTITE-243
3
234181601
WASHER-LOCK HELICAL
4
234081600
WASHER-FLAT DIN.125A-A2
5
293300083
O-RING
6
275500545
INJECTOR-AIR
7
293300084
8
270600030
RING-INJECTOR
9
293300076
RING-O
10
293650023
CLAMP-TRIDON
11
275500549
HOSE-1/4 (10M/PAC)
12
275500540
MODULE-FUEL ASS Y
13
275500559
HOSE-ASSY
14
275500508
HOSE-ASS Y
15
293650140
CLAMP-OETIKER 162
17
293750008
TIE-RAP 350MM
18
234032600
WASHER-FLAT DIN.9021B-A2
19
270600012
LEVEL-SENSOR
20
234052400
WASHER-FLAT DIN.7349
21
275500505
VALVE-CHECK
22
232551200
NUT-STOP ELASTIC DIN.985
23
293650050
CLAMP-CLIC
24
293710059
FITTING-Y
25
293730006
DART-BLACK
26
293650128
HOSE CLAMP
27
293830077
PAD-RUBBER
28
275500427
TANK-FUEL
29
293150037
RIVET-AVDEL 3/16
30
275500539
HOSE-FIL NECK
31
293250029
GASKET
32
275500231
NECK-FILLER
33
241140060
SCREW-PT.HEX.FLANGE K40 X 10
34
293720029
GROMMET
35
293250075
36
211100012
NUT-NECK FILLER FUEL
37
275500430
CAP-FUEL SUB
38
293000034
CAP-SNAP BLACK
39
275500398
40
293850036
STRAP-FUEL TANK
41
293850069
CLIP-STRAP 90
42
275500556
DISTRIBUTOR-FUEL
43
275500460
INJECTOR-FUEL
44
205061260
SCREW-SOCKET HD.DIN.912A2
45
275500558
46
293300070
47
275500557
48
293300069
49
270600022
HOSE-PRESSURE
50
51
205051260
52
275500538
ADAPTER-AIR
53
275500543
PLATE-RETAINNER
54
55
275500544
CAP
56
275500463
REGULATOR-AIR
57
275500456
58
275500455
59
275500464
REGULATOR-FUEL
60
275500449
COVER
61
293300072
62
275500465
SPACER
63
293300073
64
293800070
LOCT-ANTISEIZE
65
232561600
NUT-STOP ELASTIC DIN.985-A2
66
293750001
TIE-RAP 94MM
67
291001399
TIE-CLAMP
68
293250088
69
293850064
70
71
390407900
RIVET-POP 1/8
72
275500518
CHAIN-CAP FUEL
73
219700368
BOSCH SERVICE FILTER
