見出番号 |
部品番号 |
部品名 |
数量 |
1 |
290888812 |
ENGINE BLOCK ASSY.
|
|
2 |
290632010 |
PIN-CENTER
|
|
3 |
290956775 |
OIL SPRAY NOZZLE
|
|
4 |
290430623 |
GASKET RING A
|
|
5 |
290240233 |
PLUG SCREW M16
|
|
6 |
420250015 |
ALUMINUM WASHER
|
|
7 |
290841923 |
PLUG SCREW M12
|
|
8 |
290641120 |
TORX SCREW M10 X 82
|
|
9 |
290641203 |
TORX FLANGE SCREW
|
|
10 |
290631300 |
O-RING
|
|
11 |
290641170 |
PLUG SCREW M30
|
|
12 |
290249073 |
GROOVED PIN
|
|
13 |
290430405 |
O-RING
|
|
14 |
290660110 |
PLUG COVER
|
|
15 |
290811790 |
ENGINE BRACKET FRONT
|
|
16 |
290641188 |
TORX FLANGE SCREW
|
|
17 |
290811785 |
ENGINE BRACKET PTO EXH.
|
|
18 |
290641188 |
TORX FLANGE SCREW
|
|
19 |
290641213 |
TORX FLANGE SCREW
|
|
20 |
290811780 |
ENGINE BRACKET PTO INL.
|
|
21 |
290851740 |
RETAINING PLATE
|
|
22 |
290641213 |
TORX FLANGE SCREW
|
|
23 |
290660290 |
HOSE BRACKET
|
|
24 |
290236252 |
CHAIN TENSIONER
|
|
25 |
290430623 |
GASKET RING A
|
|
26 |
290640453 |
PLUG SCREW M16
|
|
27 |
290847970 |
SPACER
|
|
28 |
290660090 |
RUBBER BRACKET
|
|
29 |
290827968 |
WASHER M6
|
|
30 |
290641258 |
TORX FLANGE SCREW
|
|
31 |
290256777 |
OIL PRESSURE SWITCH
|
|
32 |
290664030 |
KNOCK SENSOR
|
|
33 |
290641188 |
TORX FLANGE SCREW
|
|
34 |
290888850 |
OIL RADIATOR
|
|
35 |
290250055 |
O-RING
|
|
36 |
290641048 |
TORX FLANGE SCREW
|
|
37 |
290922795 |
FORM HOSE
|
|
38 |
290922790 |
FORM HOSE
|
|
39 |
290851663 |
CLAMP
|
|
40 |
290851673 |
GEAR CLAMP
|
|
41 |
290888993 |
ELECTRIC STARTER ASSY
|
|
42 |
290631310 |
O-RING
|
|
43 |
290664710 |
CARBON BRUSH SET
|
|
44 |
290834521 |
STARTER GEAR 9T
|
|
45 |
711845600 |
RING-RETAINING
|
|
46 |
290641238 |
TORX FLANGE SCREW
|
|
47 |
290232480 |
BUSHING-NEEDLE
|
|
48 |
290834530 |
DRIVE GEAR 35T
|
|
49 |
420890632 |
BENDIX STARTER
|
|
50 |
711238300 |
SPRING-DISK
|
|
51 |
711827261 |
WASHER-THRUST
|
|
52 |
290956941 |
OIL LEVEL TUBE
|
|
53 |
290950810 |
O-RING
|
|
54 |
290956931 |
OIL LEVEL GAUGE
|
|
55 |
290889770 |
SET-GASKET 1503
|
|
55 |
293800060 |
LOCTITE-243
Loctite-243,
|
|
55 |
413707000 |
DOW CORNING 111
Molykote
|
|
55 |
293800081 |
LOCTITE-5910
Loctite
|
|
55 |
293550021 |
GREASE-ISOFLEX
Grease-Isoflex,
|
|
56 |
415150315 |
|
|
|
