見出番号 |
部品番号 |
部品名 |
数量 |
1 |
207087060 |
SCREW-HEX.CAP DIN.931A2
|
|
2 |
293800060 |
LOCTITE-243
|
|
3 |
234181601 |
WASHER-LOCK HELICAL
|
|
4 |
234081600 |
WASHER-FLAT DIN.125A-A2
|
|
5 |
293300083 |
O-RING
|
|
6 |
275500545 |
INJECTOR-AIR
|
|
7 |
293300084 |
O-RING
|
|
8 |
270600030 |
RING-INJECTOR
|
|
9 |
293300076 |
RING-O
|
|
10 |
293650023 |
CLAMP-TRIDON
|
|
11 |
275500549 |
HOSE-1/4 (10M/PAC)
|
|
12 |
204250212 |
MODULE-FUEL ASSY.
|
|
13 |
204250213 |
HOSE-OUTLET ASSY.
|
|
14 |
275500508 |
HOSE-ASS Y
|
|
15 |
293650140 |
CLAMP-OETIKER 162
|
|
17 |
293650139 |
CLAMP
|
|
18 |
234032600 |
WASHER-FLAT DIN.9021B-A2
|
|
19 |
270600012 |
LEVEL-SENSOR
|
|
20 |
234052400 |
WASHER-FLAT DIN.7349
|
|
21 |
275500505 |
VALVE-CHECK
|
|
22 |
232551200 |
NUT-STOP ELASTIC DIN.985
|
|
23 |
293650050 |
CLAMP-CLIC
|
|
24 |
293710059 |
FITTING-Y
|
|
25 |
293730006 |
DART-BLACK
|
|
26 |
293650128 |
HOSE CLAMP
|
|
27 |
204050298 |
PAD-RUBBER
|
|
28 |
204560197 |
TANK-FUEL/25GAL.
|
|
29 |
293150011 |
RIVET-POP 3/16
|
|
30 |
204250135 |
HOSE-FIL.NECK
|
|
31 |
293250029 |
GASKET
|
|
32 |
275500247 |
NECK-FILLER
|
|
33 |
241140060 |
SCREW-PT.HEX.FLANGE K40 X 10
|
|
34 |
293720029 |
GROMMET
|
|
35 |
293250075 |
GASKET
|
|
36 |
211100012 |
NUT-NECK FILLER FUEL
|
|
37 |
275500153 |
CAP-FUEL SUB.
|
|
38 |
293000034 |
CAP-SNAP BLACK
|
|
39 |
275500398 |
VALVE-CHECK
|
|
40 |
293850026 |
STRAP-FUEL TANK
|
|
41 |
293850024 |
CLIP-STRAP
|
|
42 |
275500541 |
DISTRIBUTOR-FUEL
|
|
43 |
275500460 |
INJECTOR-FUEL
|
|
44 |
205061260 |
SCREW-SOCKET HD.DIN.912A2
|
|
45 |
275500511 |
HOSE-ASS Y
|
|
46 |
293300070 |
RING-O
|
|
47 |
275500519 |
HOSE-ASS Y
|
|
48 |
293300069 |
RING-O
|
|
49 |
270600022 |
HOSE-PRESSURE
|
|
50 |
293300070 |
RING-O
|
|
51 |
205051260 |
SCREW-SOCKET HD.DIN.912A2
|
|
52 |
275500538 |
ADAPTER-AIR
|
|
53 |
275500543 |
PLATE-RETAINNER
|
|
54 |
293300069 |
RING-O
|
|
55 |
275500544 |
CAP
|
|
56 |
275500463 |
REGULATOR-AIR
|
|
57 |
275500456 |
PLATE-RETAINNER
|
|
58 |
275500455 |
PLATE-RETAINNER
|
|
59 |
275500464 |
REGULATOR-FUEL
|
|
60 |
275500449 |
COVER
|
|
61 |
293300072 |
RING-O
|
|
62 |
275500465 |
SPACER
|
|
63 |
293300073 |
RING-O
|
|
64 |
293800070 |
LOCT-ANTISEIZE
|
|
65 |
232561600 |
NUT-STOP ELASTIC DIN.985-A2
|
|
66 |
293750001 |
TIE-RAP 94MM
|
|
67 |
291001399 |
TIE-CLAMP
|
|
68 |
293250088 |
GASKET
|
|
69 |
293850025 |
STRAP-FUEL TANK
|
|
70 |
293850024 |
CLIP-STRAP
|
|
71 |
390407900 |
RIVET-POP 1/8
|
|
72 |
275500015 |
CHAIN-CAP OIL
|
|
73 |
204130018 |
RING-9 STUD
|
|
74 |
293800038 |
LOCTITE-518
|
|
75 |
293370002 |
CIRCLIP-SSTL.5MM.DIN.6799
|
|
76 |
275500067 |
HOSE-FIL NECK
|
|
77 |
293150057 |
RIVET-POP 1/8
|
|
78 |
234051500 |
WASHER-FLAT DIN.125A
|
|
79 |
232551600 |
NUT-STOP ELASTIC DIN.985A2
|
|
80 |
292000415 |
PAD-RUBBER
|
|
81 |
207162060 |
SCREW-HEX.CAP DIN.933A2
|
|
82 |
234062600 |
WASHER-FLAT DIN.9021B-A2
|
|
83 |
204060702 |
PAD-RUBBER/MUFFLER
|
|
84 |
219700368 |
BOSCH SERVICE FILTER
|
|
