見出番号 |
部品番号 |
部品名 |
数量 |
1 |
6D3-15100-01-94 |
ｸﾗﾝｸｹ-ｽｱｾﾝﾌﾞﾘ
|
|
2 |
99530-10014 |
ﾋﾟﾝ,ﾀﾞｳｴﾙ
|
|
3 |
6D3-51129-00 |
ﾆﾂﾌﾟﾙ
|
|
4 |
6D3-W009B-11-94 |
ｼﾘﾝﾀﾞﾌﾞﾛﾂｸｱｾﾝﾌﾞﾘ
|
|
5 |
90116-10619 |
BOLT, STUD
|
|
6 |
90105-093A5 |
BOLT, FLANGE
|
|
7 |
90201-096J9 |
WASHER, PLATE
|
|
8 |
99530-10014 |
ﾋﾟﾝ,ﾀﾞｳｴﾙ
|
|
9 |
90109-06051 |
BOLT
|
|
10 |
90105-06033 |
BOLT, FLANGE
|
|
11 |
90105-06M17 |
BOLT, FLANGE
|
|
12 |
69J-11301-10 |
ｱﾉｰﾄﾞｶﾊﾞｰｱｾﾝﾌﾞﾘ
|
|
13 |
68V-11325-02 |
ｱﾉ-ﾄﾞ
|
|
14 |
67F-11328-00 |
ｸﾞﾛﾒﾂﾄ
|
|
15 |
90105-06M07 |
ﾎﾞﾙﾄ,ﾌﾗﾝｼﾞ
|
|
16 |
90430-06M03 |
ｶﾞｽｹﾂﾄ
|
|
17 |
97595-08540 |
ﾎﾞﾙﾄ,ｳｲｽﾞﾜﾂｼﾔ
|
|
18 |
6B6-1310A-01-94 |
ﾊﾟﾝ,ｵｲﾙ
|
|
19 |
6B6-1310A-00-94 |
ﾊﾟﾝ,ｵｲﾙ
*1
|
|
20 |
93603-14M15 |
ﾋﾟﾝ, ﾀﾞｳｴﾙ (6T5)
*1
|
|
21 |
6B6-13557-01 |
ｶﾞｽｹﾂﾄ
*1
|
|
22 |
97513-06520 |
BOLT, WITH WASHER
|
|
23 |
60E-13161-00 |
PIPE, DELIVERY 1
|
|
24 |
93210-06667 |
O-ﾘﾝｸﾞ
|
|
25 |
95027-06010 |
BOLT, FLANGE
|
|
26 |
99530-08012 |
PIN, DOWEL
|
|
27 |
93210-08001 |
O-ﾘﾝｸﾞ
|
|
28 |
5GH-13440-20 |
ｴﾚﾒﾝﾄｱｾﾝﾌﾞﾘ,ｵｲﾙｸﾘ-ﾅ
|
|
29 |
90401-20007 |
ﾎﾞﾙﾄ,ﾕﾆｵﾝ
|
|
|
