見出番号 |
部品番号 |
部品名 |
数量 |
1 |
65U-14527-01 |
PLATE
|
|
2 |
97013-06016 |
ﾎﾞﾙﾄ
|
|
3 |
92903-06600 |
ﾜﾂｼﾔ,ﾌﾟﾚ-ﾄ
|
|
4 |
90116-08M60 |
ﾎﾞﾙﾄ,ｽﾀﾂﾄﾞ
|
|
5 |
90179-08M15 |
ﾅﾂﾄ
|
|
6 |
65U-13556-00 |
GASKET, MANIFOLD
|
|
7 |
65U-13555-00-8P |
MANIFOLD, INTAKE
|
|
8 |
65U-13566-00 |
GASKET
|
|
9 |
97013-06035 |
ﾎﾞﾙﾄ
|
|
10 |
92903-06600 |
ﾜﾂｼﾔ,ﾌﾟﾚ-ﾄ
|
|
11 |
97013-06025 |
ﾎﾞﾙﾄ
|
|
12 |
92903-06600 |
ﾜﾂｼﾔ,ﾌﾟﾚ-ﾄ
|
|
13 |
65U-13610-00 |
REED VALVE ASSY
|
|
14 |
65U-W0004-00 |
REED SET
|
|
15 |
97880-05016 |
SCREW,PANHEAD
|
|
16 |
92990-05600 |
ﾜﾂｼﾔ,ﾌﾟﾚ-ﾄ
|
|
17 |
65U-14283-00 |
COVER, CARBURETOR 1
|
|
18 |
90109-05MA0 |
BOLT
|
|
19 |
62T-14435-00 |
ｸﾞﾛﾒﾂﾄ
|
|
20 |
93210-13M63 |
O-ﾘﾝｸﾞ
|
|
21 |
65U-14284-02-8P |
COVER, CARBURETOR 2
|
|
22 |
6E5-13552-00 |
NOZZLE
|
|
23 |
65U-14451-00 |
ELEMENT, AIR CLEANER
|
|
24 |
65U-14469-00 |
FUNNEL, AIR
|
|
25 |
65U-14477-00 |
PLATE
|
|
26 |
97095-05010 |
BOLT
|
|
27 |
92995-05600 |
WASHER
|
|
28 |
65U-13674-00 |
GASKET, AIR COOLER COVER 1
|
|
29 |
90109-06M76 |
BOLT
|
|
30 |
65U-14255-00 |
PLATE
|
|
31 |
97013-06014 |
BOLT
|
|
32 |
92903-06600 |
ﾜﾂｼﾔ,ﾌﾟﾚ-ﾄ
|
|
33 |
90201-06M31 |
ﾜﾂｼﾔ,ﾌﾟﾚ-ﾄ
|
|
34 |
663-45119-00 |
ｷﾔﾂﾌﾟ,ｸﾞﾘ-ｽﾆﾂﾌﾟﾙ
|
|
35 |
61L-5169A-00 |
ﾆﾂﾌﾟﾙ,ｸﾞﾘｽ
|
|
36 |
90445-09M31 |
HOSE (L250)
|
|
37 |
90465-11M10 |
ｸﾗﾝﾌﾟ
|
|
38 |
663-45119-00 |
ｷﾔﾂﾌﾟ,ｸﾞﾘ-ｽﾆﾂﾌﾟﾙ
|
|
39 |
61L-5169A-00 |
ﾆﾂﾌﾟﾙ,ｸﾞﾘｽ
|
|
|
