見出番号 |
部品番号 |
部品名 |
数量 |
1 |
66H-14301-03 |
ｷﾔﾌﾞﾚﾀｱｾﾝﾌﾞﾘ 1
|
|
2 |
66H-14302-03 |
ｷﾔﾌﾞﾚﾀｱｾﾝﾌﾞﾘ 2
|
|
3 |
66H-14303-03 |
ｷﾔﾌﾞﾚﾀｱｾﾝﾌﾞﾘ 3
|
|
4 |
6M6-14503-00 |
ｽｸﾘｭｰ
|
|
5 |
3G2-14231-27 |
JET, MAIN (#135)
|
|
6 |
6K8-14564-00 |
O-ﾘﾝｸﾞ
|
|
7 |
6K8-24411-20 |
ﾀﾞｲﾔﾌﾗﾑ
|
|
8 |
6M6-24413-01 |
BODY 2
|
|
9 |
65U-24421-00 |
ﾊﾞﾙﾌﾞ,ﾁｴﾂｸ
|
|
10 |
65U-24492-00 |
ﾌﾞｯｼｭ,ﾌｭｴﾙﾎﾟﾝﾌﾟ
|
|
11 |
6K8-24421-10 |
ﾊﾞﾙﾌﾞ,ﾁｴﾂｸ
|
|
12 |
6K8-24431-20 |
ｶﾞｽｹﾂﾄ,ﾌﾕｴﾙﾎﾟﾝﾌﾟ 1
|
|
13 |
6K8-24452-10 |
ｶﾊﾞ-
|
|
14 |
6K8-14563-00 |
O-ﾘﾝｸﾞ
|
|
15 |
6K8-14503-02 |
ｽｸﾘｭｰ
|
|
16 |
6K8-14521-10 |
ｽｸﾘｭｰ
|
|
17 |
830-14231-19 |
JET, MAIN (# 95)
UR/CARBURETOR-2
|
|
17 |
830-14231-20 |
JET, MAIN (#100)
UR/CARBURETOR-1
|
|
17 |
830-1423A-70 |
JET, MAIN (#975)
UR/CARBURETOR-3
|
|
18 |
6R7-14569-00 |
ｽﾄﾚ-ﾅ
|
|
19 |
64T-14916-01 |
NEEDLE
|
|
20 |
6K8-14547-01 |
ｱ-ﾑ,ﾌﾛ-ﾄ
|
|
21 |
63M-14253-00 |
SPRING
|
|
22 |
6R7-14541-00 |
ﾀﾞｲﾔﾌﾗﾑ,ﾎﾟﾝﾌﾟ
|
|
23 |
6R7-14542-00 |
ﾎﾞﾃﾞ-,ﾎﾟﾝﾌﾟ 1
|
|
24 |
6K8-14536-11 |
ｶﾞｽｹﾂﾄ
|
|
25 |
6K8-14591-10 |
SCREW
|
|
26 |
6K8-14527-11 |
ﾌﾟﾚ-ﾄ
|
|
27 |
439-14186-00 |
ﾋﾟﾝ,ﾌﾛ-ﾄ
|
|
28 |
6R7-24412-01 |
BODY 1
|
|
29 |
6K8-14523-11 |
ｽｸﾘﾕ,ｽﾄﾂﾌﾟ
|
|
30 |
6M6-14521-01 |
ｽｸﾘﾕ,ｱｼﾞﾔｽﾄ
CARBURETOR-1
|
|
31 |
812-14235-00 |
ﾜﾂｼﾔ,ﾆ-ﾄﾞﾙ
|
|
32 |
47X-14133-00 |
ｽﾌﾟﾘﾝｸﾞ,ｽﾛﾂﾄﾙｽﾄﾂﾌﾟ
CARBURETOR-1
|
|
33 |
97980-05330 |
ｽｸﾘﾕ,ｳｲｽﾞﾜﾂｼﾔ
|
|
34 |
812-14147-00 |
O-ﾘﾝｸﾞ
|
|
35 |
6K8-14946-10 |
METERING NEEDLE
|
|
36 |
6K8-14471-10 |
ｷﾔﾂﾌﾟ,ｷﾔﾌﾞﾚﾀ
|
|
37 |
3KW-14932-00 |
ｽﾌﾟﾘﾝｸﾞ,ｽﾛﾂﾄﾙ 2
|
|
38 |
65U-14923-10 |
SCREW, PILOT
|
|
39 |
6K8-14589-00 |
ｽﾌﾟﾘﾝｸﾞ
|
|
40 |
822-14235-00 |
ﾜﾂｼﾔ,ﾆ-ﾄﾞﾙ
|
|
41 |
583-14561-00 |
O-ﾘﾝｸﾞ
|
|
42 |
65U-14243-00 |
PLATE
|
|
43 |
64X-14398-00 |
GASKET
|
|
44 |
64X-14162-00 |
【販売終了】BOLT, HOLDING
|
|
45 |
65U-41217-00 |
ROD, ACCEL LEVER
|
|
46 |
90445-17M03 |
HOSE (L105)
|
|
47 |
90450-17M17 |
HOSE CLAMP ASSY
|
|
48 |
65U-24315-01 |
PIPE 5
|
|
49 |
90465-11M10 |
ｸﾗﾝﾌﾟ
|
|
50 |
65U-24314-01 |
PIPE 4
|
|
51 |
90465-11M10 |
ｸﾗﾝﾌﾟ
|
|
52 |
65U-24314-01 |
PIPE 4
|
|
53 |
90465-11M10 |
ｸﾗﾝﾌﾟ
|
|
|
