見出番号 |
部品番号 |
部品名 |
数量 |
1 |
60E-13750-20 |
ｽﾛﾂﾄﾙﾎﾞﾃﾞ-ｱｾﾝﾌﾞﾘ
|
|
2 |
68V-81147-00 |
SCREW 3
|
|
3 |
63P-14446-00 |
ﾎﾞﾙﾄ
|
|
4 |
60E-12880-10 |
ﾃﾞﾘﾊﾞﾘｲﾊﾟｲﾌﾟ
|
|
5 |
60E-14216-00 |
ｽｸﾘﾕ
|
|
6 |
5FL-14987-10 |
ﾎ-ｽ
|
|
7 |
5FL-14349-10 |
ﾊﾟｲﾌﾟ
|
|
8 |
4N0-14251-00 |
NIPPLE
|
|
9 |
5PW-14396-00 |
ﾊﾟｲﾌﾟ
|
|
10 |
3KW-14932-00 |
ｽﾌﾟﾘﾝｸﾞ,ｽﾛﾂﾄﾙ 2
|
|
11 |
69J-14321-00 |
SCREW, THROTTLE
|
|
12 |
90430-09002 |
GASKET
|
|
13 |
60E-13761-10 |
ｲﾝｼﾞｴｸﾀｱｾﾝﾌﾞﾘ
|
|
14 |
60E-14147-00 |
O-ﾘﾝｸﾞ
|
|
15 |
65L-85886-00 |
ｻ-ﾓｾﾝｻ-
|
|
16 |
60E-14358-00 |
ﾅﾂﾄ
|
|
17 |
60E-82380-10 |
ｾﾝｻ-,ﾌﾟﾚﾂｼﾔ-
|
|
18 |
68V-81145-01 |
ｽｸﾘﾕ 1
|
|
19 |
60E-85885-10 |
ｽﾛﾂﾄﾙｾﾝｻｱｾﾝﾌﾞﾘ
|
|
20 |
4BH-14923-00 |
SCREW, PILOT
|
|
21 |
4BH-14134-00 |
SPRING, AIR ADJUSTING
|
|
22 |
3L5-14962-00 |
WASHER
|
|
23 |
3H1-14147-00 |
O-RING
|
|
24 |
60E-13545-00 |
ﾎ-ｽ 1
|
|
25 |
60E-13546-00 |
ﾎ-ｽ 2
|
|
26 |
60E-13547-00 |
ﾎ-ｽ 3
|
|
27 |
60E-13548-00 |
ﾎ-ｽ,ｴｱ 4
|
|
28 |
60E-13660-00 |
ﾊﾞｲﾊﾟｽﾊﾞﾙﾌﾞﾓｰﾀｰｱｾﾝﾌﾞﾘ
|
|
|
