見出番号 |
部品番号 |
部品名 |
数量 |
1 |
274001434 |
MANIFOLD
Exhaust
|
|
2 |
420641198 |
TORX FLANGE SCREW
Flanged
|
|
3 |
270000767 |
SPACER
Spacer
|
|
4 |
234082600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
5 |
250000525 |
SCREW-HEX CAP DIN
Hex.
|
|
6 |
234082600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
7 |
207382560 |
SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.
|
|
8 |
270000886 |
RUBBER MOUNT
Rubber
|
|
9 |
250200018 |
WASHER-CONE
Cone
|
|
10 |
250000334 |
SCREW-SOCKET DIN
Socket
|
|
11 |
270000770 |
SHIM 1-3MM
Shim
|
|
12 |
270000763 |
SPACER
Spacer
|
|
13 |
234082600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
14 |
250000525 |
SCREW-HEX CAP DIN
Hex.
|
|
15 |
234082600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
16 |
207382560 |
SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.
|
|
17 |
270000882 |
RUBBER MOUNT
Rubber
|
|
18 |
250200018 |
WASHER-CONE
Cone
|
|
19 |
250000334 |
SCREW-SOCKET DIN
Socket
|
|
20 |
270000762 |
SHIM 1-3MM
Shim
|
|
21 |
270000766 |
SPACER
Spacer
|
|
22 |
234082600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
23 |
250000525 |
SCREW-HEX CAP DIN
Hex.
|
|
24 |
234082600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
25 |
207382560 |
SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.
|
|
26 |
270000882 |
RUBBER MOUNT
Rubber
|
|
27 |
250200018 |
WASHER-CONE
Cone
|
|
28 |
250000334 |
SCREW-SOCKET DIN
Socket
|
|
29 |
270000762 |
SHIM 1-3MM
Shim
|
|
30 |
273000250 |
SILENC-AIR LOW
Air
|
|
31 |
273000249 |
SILENC-AIR UPP
Air
|
|
32 |
293250190 |
OIL SEAL
Seal
|
|
33 |
269501718 |
CLIP
Clip
|
|
34 |
273000252 |
INTAKE HOSE
Intake
|
|
35 |
273000257 |
CONNECT. HOSE
Connector
|
|
36 |
273000253 |
INTAKE TUBE
Intake
|
|
37 |
269501299 |
STRAP
Strap
|
|
38 |
293720064 |
GROMMET
Grommet
|
|
39 |
275500454 |
VALVE-CHECK
Check
|
|
40 |
219903177 |
NOTICE LABEL
Notice
|
|
41 |
293200123 |
NEOPRENE SEAL
Neoprene
|
|
42 |
273000271 |
DEFLECTOR
Deflector
|
|
43 |
270000791 |
AIRBOX SUPPORT
Air
|
|
44 |
234062600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
45 |
207361660 |
SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.
|
|
46 |
420942108 |
PANEL NUT
Panel
|
|
47 |
234062600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
48 |
207362560 |
SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.
|
|
49 |
273000260 |
AIRBOX BRACKET
Air
|
|
50 |
273000261 |
STRAP
Strap
|
|
51 |
207361260 |
SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.
|
|
52 |
270000807 |
HOSE-FORMED
Formed
|
|
53 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
54 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
55 |
273000276 |
INTAKE TUBE
Intake
|
|
56 |
273000277 |
INTAKE FITTING
Intake
|
|
57 |
293650179 |
CLAMP-TRIDON
Tridon
|
|
58 |
293650179 |
CLAMP-TRIDON
Tridon
|
|
59 |
293650179 |
CLAMP-TRIDON
Tridon
|
|
60 |
270000854 |
STRAP ANCHOR
Strap
|
|
61 |
243162060 |
SCREW-PLASTITE HEXUNSL
Hex.
|
|
62 |
293750002 |
TIE-RAP 130MM
Tie-Rap
|
|
