1

207382560

SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.

2

207284060

SCREW-HEX.CAP-DIN.931A2 S.GRIP
Hex.

7

207382560

SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.

11

219903177

NOTICE LABEL
Notice

13

234082600

WASHER-FLAT DIN.9021B-A2
Flat

15

250000287

SCREW-PT.FLANGE PAN HDTORX.K40 X 16
Flanged

16

250200018

WASHER-CONE
Cone

33

270000762

SHIM 1-3MM
Shim

43

270000815

SPACER REAR
Rear

49

270000864

FORMED HOSE
Formed

59

273000234

BREATHER
Breather

74

273000288

AIRBOX COVER
Air

75

273000289

AIRBOX BASE
Air

76

273000290

TUBE
Air

84

273000301

INTAKE TUBE
Intake

89

273000311

INTAKE TUBE
Intake

90

273000317

HOSE-INTAKE
Rear

91

273000320

CONNECT HOSE
Hose

107

293650051

CLAMP-TRIDON
Tridon

108

293650179

CLAMP-TRIDON
Tridon

112

293650179

CLAMP-TRIDON
Tridon

113

293650217

CRIMP CLAMP
Crimp

116

293750002

TIE-RAP 130MM
Tie-Rap

123

420641198

TORX FLANGE SCREW
Flanged

126

420822174

FORMED HOSE
Formed

128

708000759

STOPPER-RUBBER
Rubber

129

274001434

MANIFOLD
Exhaust

131

270000882

RUBBER MOUNT
Rubber

133

270000882

RUBBER MOUNT
Rubber

137

270000818

SPACER FRONT
Front

140

270000885

RUBBER MOUNT
Rubber
