1

207382560

SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.

2

207284060

SCREW-HEX.CAP-DIN.931A2 S.GRIP
Hex.

7

250000525

SCREW-HEX CAP DIN
Hex.

8

250000526

SCREW-HEX CAP DIN
Hex.

11

219903177

NOTICE LABEL
Notice

13

234082600

WASHER-FLAT DIN.9021B-A2
Flat

14

243162060

SCREW-PLASTITE HEXUNSL
Hex.

15

250000287

SCREW-PT.FLANGE PAN HDTORX.K40 X 16
Flanged

16

250200018

WASHER-CONE
Cone

26

270000809

HOSE-FORMED
Formed

29

270000767

SPACER
Spacer

30

270000763

SPACER
Spacer

31

270000766

SPACER
Spacer

33

270000762

SHIM 1-3MM
Shim

35

270000770

SHIM 1-3MM
Shim

40

270000804

COVER
Engine

48

270000854

STRAP ANCHOR
Strap

59

273000234

BREATHER
Breather

76

273000290

TUBE
Air

77

273000291

INTAKE TUBE
Intake

79

273000295

CONNECT HOSE
Hose

80

273000297

AIRBOX COVER
Air

81

273000298

AIRBOX BASE
Air

99

275500664

RETAINER
Retainer

102

293050001

WASHER-8MM
Flat

107

293650051

CLAMP-TRIDON
Tridon

108

293650179

CLAMP-TRIDON
Tridon

116

293750002

TIE-RAP 130MM
Tie-Rap

123

420641198

TORX FLANGE SCREW
Flanged

128

708000759

STOPPER-RUBBER
Rubber

129

274001434

MANIFOLD
Exhaust

130

270000886

RUBBER MOUNT
Rubber

131

270000882

RUBBER MOUNT
Rubber

133

270000882

RUBBER MOUNT
Rubber
