1

207382560

SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.

2

207284060

SCREW-HEX.CAP-DIN.931A2 S.GRIP
Hex.

7

207382560

SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.

11

219903177

NOTICE LABEL
Notice

13

234082600

WASHER-FLAT DIN.9021B-A2
Flat

15

250000287

SCREW-PT.FLANGE PAN HDTORX.K40 X 16
Flanged

16

250200018

WASHER-CONE
Cone

25

270000809

HOSE-FORMED
Formed

33

270000762

SHIM 1-3MM
Shim

43

270000815

SPACER REAR
Rear

59

273000234

BREATHER
Breather

76

273000290

TUBE
Air

77

273000291

INTAKE TUBE
Intake

78

273000292

CONNECT HOSE
Hose

80

273000297

AIRBOX COVER
Air

81

273000298

AIRBOX BASE
Air

99

275500664

RETAINER
Retainer

107

293650051

CLAMP-TRIDON
Tridon

108

293650179

CLAMP-TRIDON
Tridon

116

293750002

TIE-RAP 130MM
Tie-Rap

123

420641198

TORX FLANGE SCREW
Flanged

128

708000759

STOPPER-RUBBER
Rubber

129

274001434

MANIFOLD
Exhaust

131

270000882

RUBBER MOUNT
Rubber

133

270000882

RUBBER MOUNT
Rubber

137

270000818

SPACER FRONT
Front

140

270000885

RUBBER MOUNT
Rubber
