1

207284060

SCREW-HEX.CAP-DIN.931A2 S.GRIP
Hex.

5

207382560

SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.

7

219903177

NOTICE LABEL
Notice

10

234082600

WASHER-FLAT DIN.9021B-A2
Flat

11

243162060

SCREW-PLASTITE HEXUNSL
Hex.

12

250000287

SCREW-PT.FLANGE PAN HDTORX.K40 X 16
Flanged

13

250200018

WASHER-CONE
Cone

15

250000525

SCREW-HEX CAP DIN
Hex.

19

270000767

SPACER
Spacer

20

270000763

SPACER
Spacer

21

270000766

SPACER
Spacer

22

270000762

SHIM 1-3MM
Shim

23

270000770

SHIM 1-3MM
Shim

25

270000804

COVER
Engine

29

270000854

STRAP ANCHOR
Strap

30

270000809

HOSE-FORMED
Formed

31

270000882

RUBBER MOUNT
Rubber

33

270000886

RUBBER MOUNT
Rubber

35

273000234

BREATHER
Breather

49

273000290

TUBE
Air

50

273000291

INTAKE TUBE
Intake

52

273000295

CONNECT HOSE
Hose

53

273000297

AIRBOX COVER
Air

54

273000298

AIRBOX BASE
Air

64

274001504

MANIFOLD
Exhaust

65

275500664

RETAINER
Retainer

70

293650051

CLAMP-TRIDON
Tridon

73

293650179

CLAMP-TRIDON
Tridon

77

293750002

TIE-RAP 130MM
Tie-Rap

84

420641198

TORX FLANGE SCREW
Flanged

88

708000759

STOPPER-RUBBER
Rubber
