見出番号 |
部品番号 |
部品名 |
数量 |
1 |
207362060 |
SCREW-HEX CAP DIN933A2
Hex.
|
|
1 |
207361660 |
SCREW-HEX.CAP DIN.933A2 S.GRIP
Hex.
|
|
4 |
234062600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
4 |
234062600 |
WASHER-FLAT DIN.9021B-A2
Flat
|
|
8 |
276000100 |
PRESSURE CAP ASSY
Pressure
|
|
10 |
276000240 |
HOSE
Radiator
|
|
12 |
276000244 |
HOSE-FORMED
Formed
|
|
13 |
276000245 |
HOSE-FORMED
Lower
|
|
14 |
276000246 |
HOSE-FORMED
Formed
|
|
16 |
276000265 |
TANK-COOLANT
Coolant
|
|
18 |
278002895 |
SENSOR-LIQUID
Temperature
|
|
20 |
293650012 |
CLAMP-OETIKER
Oetiker
|
|
21 |
293650019 |
CLAMP-TRIDON
Tridon
|
|
23 |
293650025 |
CLAMP-OETIKER
Oetiker
|
|
24 |
293650030 |
CLAMP-OETIKER 185
Oetiker
|
|
25 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
27 |
293650115 |
CLAMP-SPRING
Spring
|
|
28 |
293650170 |
HOSE CLAMP
Tridon
|
|
29 |
276000099 |
HOSE-19MM
Hose
|
|
30 |
276000394 |
HOSE 6-4MM
Master-Hose
|
|
31 |
293650171 |
HOSE CLAMP
Tridon
|
|
32 |
293650172 |
HOSE CLAMP
Tridon
|
|
33 |
293650185 |
CLAMP-TRIDON
Tridon
|
|
34 |
409901800 |
TUBING - INSULATING 13 MM
Tubing
|
|
35 |
293710116 |
FITTING-T
T-Fitting
|
|
36 |
293710131 |
FITTING-T
T-Fitting
|
|
37 |
293710132 |
FITTING-T
T-Fitting
|
|
38 |
293710143 |
SENSOR
Sensor
|
|
39 |
293720029 |
GROMMET
Grommet
|
|
40 |
293750001 |
TIE-RAP 94MM
Tie-Rap
|
|
41 |
293750008 |
TIE-RAP 350MM
Tie-Rap
|
|
42 |
415080200 |
POLYURETHANE HOSE
Hose,
|
|
43 |
409902200 |
TUBING-25MM
Tubing
|
|
44 |
276000151 |
HOSE-12 5MM (PC=1M)
Hose
|
|
45 |
276000151 |
HOSE-12 5MM (PC=1M)
Hose
|
|
46 |
515175319 |
TUBING-22MM
Tubing
|
|
47 |
414115200 |
TIE-RAP 180MM
Tie-Rap
|
|
48 |
276000099 |
HOSE-19MM
Hose
|
|
49 |
414518500 |
CONNECTOR-MALE
Male
|
|
50 |
276000394 |
HOSE 6-4MM
Master-Hose
|
|
51 |
409902200 |
TUBING-25MM
Tubing
|
|
