見出番号 |
部品番号 |
部品名 |
数量 |
750 |
270001002 |
COVER ASS Y
Cover
|
|
1070 |
250000933 |
HEX SEMS SCREW M8 X 30 S.GRIP
Hex
|
|
1100 |
270001029 |
RUBBER MOUNT
Rubber
|
|
1110 |
250200018 |
WASHER-CONE
Cone
|
|
1120 |
250000782 |
SCREW-HEX CAP
Hexagonal
|
|
1150 |
270000762 |
SHIM 1-3MM
Shim
|
|
1570 |
250000933 |
HEX SEMS SCREW M8 X 30 S.GRIP
Hex
|
|
1600 |
270001011 |
RUBBER MOUNT
Rubber
|
|
1610 |
250200018 |
WASHER-CONE
Cone
|
|
1620 |
250000782 |
SCREW-HEX CAP
Hexagonal
|
|
1650 |
270000762 |
SHIM 1-3MM
Shim
|
|
1820 |
250000933 |
HEX SEMS SCREW M8 X 30 S.GRIP
Hex
|
|
1850 |
270001011 |
RUBBER MOUNT
Rubber
|
|
1860 |
250200018 |
WASHER-CONE
Cone
|
|
1870 |
250000782 |
SCREW-HEX CAP
Hexagonal
|
|
1900 |
270000762 |
SHIM 1-3MM
Shim
|
|
2000a |
273000342 |
AIRBOX BASE
Airbox
|
|
2000b |
273000373 |
AIRBOX COVER
Airbox
|
|
2000e |
273000359 |
INTAKE TUBE
Intake
|
|
2000f |
273000375 |
HOSE CONNECTOR
Hose
|
|
2000g |
273000290 |
TUBE
Air
|
|
2000j |
219903177 |
NOTICE LABEL
Notice
|
|
2000k |
708000759 |
STOPPER-RUBBER
Rubber
|
|
2000m |
250000287 |
SCREW-PT.FLANGE PAN HDTORX.K40 X 16
Flanged
|
|
2300 |
270000950 |
FORMED HOSE
Formed
|
|
2305 |
273000234 |
BREATHER
Breather
|
|
2310 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
2315 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
2350 |
273000387 |
HOSE INTAKE
Hose
|
|
2370 |
293830197 |
POLYURETHANE HOSE
Hose
|
|
2380 |
293750008 |
TIE-RAP 350MM
Tie-Rap
|
|
2400 |
293650179 |
CLAMP-TRIDON
Tridon
|
|
2410 |
293650179 |
CLAMP-TRIDON
Tridon
|
|
2420 |
273000380 |
INTAKE HOSE
Intake
|
|
2430 |
293650179 |
CLAMP-TRIDON
Tridon
|
|
3000 |
276000335 |
INTERCOOLER
Intercooler.
|
|
3000a |
271001942 |
ANODE ZINC
Anode
|
|
3010 |
273000338 |
INLET HOSE
Inlet
|
|
3020 |
293650244 |
TRIDON GEAR CLAMP
Tridon
|
|
3025 |
293650179 |
CLAMP-TRIDON
Tridon
|
|
3030 |
273000377 |
OUTLET HOSE
Outlet
|
|
3040 |
293650244 |
TRIDON GEAR CLAMP
Tridon
|
|
3045 |
293650179 |
CLAMP-TRIDON
Tridon
|
|
3070 |
293850094 |
STRAP-TANK FUE
Fuel
|
|
3072 |
293850093 |
STRAP-FUEL TANK
Strap
|
|
3075 |
293850095 |
STRAP-FUEL TANK
Fuel
|
|
3080 |
293830178 |
PAD-RUBBER
Pad-Rubber
|
|
3090 |
293730016 |
DART-BLACK
Dart,
|
|
3510 |
293750001 |
TIE-RAP 94MM
Tie-Rap
|
|
3530 |
414115200 |
TIE-RAP 180MM
Tie-Rap
|
|
3540 |
414115200 |
TIE-RAP 180MM
Tie-Rap
|
|
|
