見出番号 |
部品番号 |
部品名 |
数量 |
10 |
276000420 |
HOSE
Hose
|
|
20 |
293650245 |
NORMA CLAMP
Norma
|
|
25 |
293650245 |
NORMA CLAMP
Norma
|
|
200 |
276000421 |
FORMED HOSE
Hose
|
|
210 |
293650245 |
NORMA CLAMP
Norma
|
|
215 |
293650245 |
NORMA CLAMP
Norma
|
|
500 |
276000158 |
HOSE-19MM (PC=1M)
Hose
|
|
510 |
293650019 |
CLAMP-TRIDON
Tridon
|
|
515 |
293650115 |
CLAMP-SPRING
Spring
|
|
720 |
276000100 |
PRESSURE CAP ASSY
Pressure
|
|
800 |
276000394 |
HOSE 6-4MM
Hose
|
|
810 |
293650170 |
HOSE CLAMP
Tridon
|
|
815 |
293650170 |
HOSE CLAMP
Tridon
|
|
830 |
409901800 |
TUBING - INSULATING 13 MM
Tubing
|
|
835 |
293750001 |
TIE-RAP 94MM
Tie-Rap
|
|
850 |
415080200 |
POLYURETHANE HOSE
Hose,
|
|
860 |
293750001 |
TIE-RAP 94MM
Tie-Rap
|
|
1010 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
1015 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
1020 |
409902200 |
TUBING-25MM
Tubing
|
|
1050 |
276000158 |
HOSE-19MM (PC=1M)
Hose
|
|
1060 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
1065 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
1090 |
293710131 |
FITTING-T
T-Fitting.
|
|
1090-1090a |
293710164 |
SENSOR
Temperature
|
|
1090a |
278002895 |
SENSOR-LIQUID
Temperature
|
|
1200 |
296000303 |
HOSE 12.5MM 3M/PAC
Hose
|
|
1210 |
293650172 |
HOSE CLAMP
Tridon
|
|
1215 |
293650172 |
HOSE CLAMP
Tridon
|
|
1220 |
515175319 |
TUBING-22MM
Tubing
|
|
1250 |
296000303 |
HOSE 12.5MM 3M/PAC
Hose
|
|
1260 |
293650172 |
HOSE CLAMP
Tridon
|
|
1265 |
293650172 |
HOSE CLAMP
Tridon
|
|
1270 |
515175319 |
TUBING-22MM
Tubing
|
|
1290 |
293710132 |
FITTING-T
T-Fitting
|
|
2000 |
276000244 |
HOSE-FORMED
Formed
|
|
2010 |
293650172 |
HOSE CLAMP
Tridon
|
|
2015 |
293650012 |
CLAMP-OETIKER
Oetiker
|
|
2030 |
293710116 |
FITTING-T
T-Fitting
|
|
2050 |
276000245 |
HOSE-FORMED
Lower
|
|
2060 |
293650012 |
CLAMP-OETIKER
Oetiker
|
|
2065 |
293650172 |
HOSE CLAMP
Tridon
|
|
2100 |
276000246 |
HOSE-FORMED
Formed
|
|
2110 |
293650030 |
CLAMP-OETIKER 185
Oetiker
|
|
2115 |
293650172 |
HOSE CLAMP
Tridon
|
|
2250 |
276000422 |
FORMED HOSE
Formed
|
|
2255 |
409902200 |
TUBING-25MM
Tubing
|
|
2260 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
2265 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
2270-2270a |
276000423 |
FORMED HOSE
Formed
|
|
2270a |
276000367 |
HOSE
Hose
|
|
2280 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
2285 |
293650051 |
CLAMP-TRIDON
Tridon
|
|
2340 |
293720029 |
GROMMET
Grommet
|
|
2345 |
414518500 |
CONNECTOR-MALE
Male
|
|
2350 |
276000394 |
HOSE 6-4MM
Hose
|
|
2355 |
293650170 |
HOSE CLAMP
Tridon
|
|
2360 |
293650025 |
CLAMP-OETIKER
Oetiker
|
|
4000 |
293750008 |
TIE-RAP 350MM
Tie-Rap
|
|
4020 |
414115200 |
TIE-RAP 180MM
Tie-Rap
|
|
4070 |
293750008 |
TIE-RAP 350MM
Tie-Rap
|
|
4100 |
414115200 |
TIE-RAP 180MM
Tie-Rap
|
|
|
