1

420893166

CYLINDER BLOCK W SLEEVES
Engine-Block-Ass'y-1503-Plasma.-Includes-1-to-9-

2

420632010

PIN-CENTER
Center-Pin-8-X-12-

3

420956778

OIL SPRAY NOZZLE
Oil-Hole-Adaptor-

4

420250015

ALUMINUM WASHER
Washer,-Copper-

5

420841923

PLUG SCREW M12
Plug-Screw-M12-

6

420641120

TORX-RED SHAFT SCREW M11X147
Torx-Flanged-Screw-M10-X-82-

7

420641208

HEX FLANGED SCREW M8 X 45
Torx-Flanged-Screw-M8-X-45-

8

420641317

PLUG SCREW
Plug-Screw-M20-X-1.5-

9

420232482

BUSHING-NEEDLE
Needle-Bushing-

10

420641171

PLUG SCREW M30
Plug-Screw-M30-X-1.5.-Includes-10-to-11-

11

420631300

O-RING
O-Ring-

12

420430405

O-RING
O-Ring-

13

420660110

PLUG COVER
Plug-Cover-

14

420811792

ENGINE BRACKET FRONT
Front-Engine-Bracket-

15

420641188

TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-35-

16

420811787

ENGINE BRACKET PTO EXH.
Engine-Bracket-PTO,-Exhaust-

17

420641188

TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-35-

18

420641213

TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-55-

19

420811782

ENGINE BRACKET PTO INL.
Engine-Bracket-PTO,-Intake-

20

420851740

RETAINING PLATE
Retaining-Plate-

21

420641213

TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-55-

22

420660290

HOSE BRACKET
Hose-Bracket-

23

420236259

CHAIN TENSIONER W SCREW
Chain-Tensioner-With-Screw.-Includes-23-to-26-

24

XXX

Chain-Tensioner-

25

420430623

GASKET RING A
Gasket-Ring-

26

XXX

Plug-Screw-M16-X-1.5-

27

420847971

SPACER
Spacer-

28

420660090

RUBBER BRACKET
Rubber-Bracket-

29

420827968

WASHER M6
Flat-Washer-M6-

30

420641258

SCREW TORX FLANGE M6 X 35
Flanged-Torx-Screw-M6-X-35-

31

420256916

OIL PRESSURE SWITCH
Oil-Pressure-Switch-

32

420664031

KNOCK SENSOR
Noise-Sensor-

33

420641188

TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-35-

34

420888852

OIL RADIATOR
Oil-Radiator-

35

420250055

O-RING
O-Ring-

36

420641048

TORX FLANGE SCREW
Flanged-Torx-Screw-M6-X-16-

37

420922798

FORMED HOSE
Formed-Hose-

38

420922792

FORMED HOSE
Formed-Hose-

39

420851668

GEAR CLAMP
Gear-Clamp-

40

420851673

GEAR CLAMP
Gear-Clamp-

41

420888995

ELECTRIC STARTER ASSY
Electric-Starter-Ass'y.-Includes-41-to-42-

42

420631310

O-RING
O-Ring-

43

420881340

CARBON BRUSH SET
Carbon-Brush-Set-

44

420834522

STARTER GEAR 9 T
Starter-Gear,-9-Teeth-

45

420845600

RING-RETAINING
Retaining-Ring-

46

420641238

SCREW-TORX FLANGE
Flanged-Torx-Screw-M6-X-25-

47

420249073

GROOVED PIN
Grooved-Pin-

48

420889872

FRICTION CLUTCH
Friction-Clutch-

49

420890639

BENDIX STARTER
Bendix-Starter-

50

420238300

SPRING-DISK
Spring-Washer-

51

420827261

WASHER-THRUST
Thrust-Washer-

52

420956944

OIL LEVEL TUBE
Oil-Level-Tube.-Includes-52-to-53-

53

420950810

O-RING
O-Ring-

54

420956933

OIL LEVEL GAUGE
Oil-Level-Gauge-

55

420889773

ENGINE GASKET SET
Engine-Gasket-Set-

56

420150375

BLOCK-LONG 1503 HO
Engine-Long-Block,-1503-(Plasma)-
