見出番号 |
部品番号 |
部品名 |
数量 |
4 |
276000099 |
HOSE-19MM
Hose-19-mm-
|
|
6 |
409902200 |
TUBING-25MM
Tubing-25-mm-
|
|
7 |
276000345 |
HEAT EXCHANGER
Heat-Exchanger-
|
|
8 |
276000350 |
HOSE-RIGHT
Hose-
|
|
9 |
276000351 |
HOSE-LEFT
Hose-
|
|
10 |
276000353 |
HOSE-LEFT
Hose-
|
|
12 |
276000368 |
COOLING HOSE
Cooling-Hose-
|
|
16 |
293650045 |
CLAMP-TRIDON
Tridon-Gear-Clamp-
|
|
17 |
293650185 |
CLAMP-TRIDON
Tridon-Gear-Clamp-
|
|
19 |
293650185 |
CLAMP-TRIDON
Tridon-Gear-Clamp-
|
|
22 |
293650051 |
CLAMP-TRIDON
Tridon-Gear-Clamp-
|
|
23 |
293650051 |
CLAMP-TRIDON
Tridon-Gear-Clamp-
|
|
25 |
293700052 |
FEMALE FITTING
Female-Fitting-
|
|
26 |
293700053 |
REDUCER 1-3/4 NPT
Reducer-1-3/4"-NPT-
|
|
28 |
293700054 |
MALE FITTING 3/4 NPT
Male-Fitting-3/4"-NPT-
|
|
30 |
293750008 |
TIE-RAP 350MM
Tie-Rap-350-mm-
|
|
35 |
515176044 |
STRAP-BATTERY
Battery-Strap-
|
|
