見出番号 |
部品番号 |
部品名 |
数量 |
1 |
205364060 |
SCREW-SOCKET HD.CTSK.DIN.7991
Socket-Head-Screw-M6-X-40-
|
|
2 |
205562560 |
SCREW-SOCKET M6X25
Socket-Head-Screw-M6-X-25,-Scotch-Grip-
|
|
3 |
232561200 |
NUT-STOP ELASTIC DIN985
Elastic-Stop-Nut-M6,-Brass-
|
|
4 |
232581200 |
NUT-STOP ELASTIC DIN.985
Hex.-Elastic-Nut-M8,-Brass-
|
|
5 |
234061600 |
WASHER-FLAT DIN125A-A2
Flat-Washer-M6,-Stainless-
|
|
6 |
234062600 |
WASHER-FLAT DIN.9021B-A2
Flat-Washer-M6,-Stainless-
|
|
7 |
279000164 |
WASHER
Flat-Washer-
|
|
8 |
250000572 |
TORX-HEAD SCREW M8X35
Torx-Head-Screw-M8-X-35-
|
|
9 |
250000744 |
TORX SCEW M6 X 30
Torx-Scew-M6-X-30-
|
|
10 |
250200011 |
WASHER-FLAT STLSS. M8
Flat-Washer-8-mm,-Stainless-
|
|
12 |
292000933 |
UCLAMP
U-Clamp-
|
|
13 |
292001471 |
SCREW
Square-Head-Stud-
|
|
14 |
292001503 |
PUSH NUT
Push-Nut-
|
|
15 |
292001657 |
ALUMINIUM RAIL
Aluminium-Rail-
|
|
17 |
292001663 |
FLAT WASHER 8 MM
Flat-Washer-8-mm,-Nylon-
|
|
18 |
292001668 |
RAIL SPACER
Rail-Spacer-
|
|
21 |
292001426 |
SPONSON RH
RH-Sponson-
|
|
21 |
292001427 |
SPONSON LH
LH-Sponson-
|
|
22 |
292001428 |
SPACER
RH-Stabilizer-Spacer-
|
|
22 |
292001429 |
SPACER
LH-Stabilizer-Spacer-
|
|
23 |
292001743 |
PROTECTOR
Protector-
|
|
25 |
292001775 |
RH RAIL
RH-Rail-
|
|
25 |
292001798 |
LH RAIL
LH-Rail-
|
|
26 |
292001804 |
SPONSON PLATE
Sponson-Plate-
|
|
27 |
292001805 |
SPONSON PLATE
Sponson-Plate-
|
|
28 |
292001836 |
HEAT EXCHANGER SUPPORT
Heat-Exchanger-Support-
|
|
32 |
293830037 |
WASHER-RUBBER
Rubber-Washer-
|
|
38 |
292001738 |
SPONSON MACHIN
RH-Sponson-
|
|
38 |
292001739 |
SPONSON MACHIN
LH-Sponson-
|
|
