見出番号 |
部品番号 |
部品名 |
数量 |
2 |
211000106 |
SCREW-FORMING HEXAGONAL
Hex.-Forming-Screw-M6-X-16-
|
|
13 |
278003110 |
POSITION LAMP
Position-Light-
|
|
15 |
278003112 |
SECOND HARNESS
Secondary-Harness-
|
|
17 |
278003182 |
LIGHT 360 ASS
Lampe-360-Assembly-
|
|
19 |
291002952 |
HOSE BILGEFLEX
Hose-Bilgeflex-
|
|
21 |
292001486 |
GASKET
Gasket-
|
|
22 |
293650172 |
HOSE CLAMP
Tridon-Gear-Clamp-
|
|
23 |
293710015 |
FITTING
Perko-Fitting-3/4"-
|
|
24 |
293720079 |
GROMMET-CABLE
Cable-Grommet-
|
|
27 |
295100597 |
BILGE PUMP
Bilge-Pump-
|
|
28 |
414115200 |
TIE-RAP 180MM
Tie-Rap-180-mm-
|
|
