見出番号 |
部品番号 |
部品名 |
数量 |
750-750a |
270001002 |
COVER ASS Y
CoverAss'y.Includes750TO750a*1
|
|
750a |
293250388 |
SEAL
Seal*1
|
|
1070 |
250000933 |
HEX SEMS SCREW M8 X 30 S.GRIP
HexSemsScrewM8X30S.Grip*1
|
|
1100 |
270001029 |
RUBBER MOUNT
RubberMount*1
|
|
1110 |
250200018 |
WASHER-CONE
ConeWasher*2
|
|
1120 |
250000782 |
SCREW-HEX CAP
HexagonalHeadCapScrewM8X45*2
|
|
1150 |
270000762 |
SHIM 1-3MM
Shim1.3mm*3
|
|
1570 |
250000933 |
HEX SEMS SCREW M8 X 30 S.GRIP
HexSemsScrewM8X30S.Grip*1
|
|
1600 |
270001011 |
RUBBER MOUNT
RubberMount*1
|
|
1610 |
250200018 |
WASHER-CONE
ConeWasher*2
|
|
1620 |
250000782 |
SCREW-HEX CAP
HexagonalHeadCapScrewM8X45*2
|
|
1650 |
270000762 |
SHIM 1-3MM
Shim1.3mm*3
|
|
1820 |
250000933 |
HEX SEMS SCREW M8 X 30 S.GRIP
HexSemsScrewM8X30S.Grip*1
|
|
1850 |
270001011 |
RUBBER MOUNT
RubberMount*1
|
|
1860 |
250200018 |
WASHER-CONE
ConeWasher*2
|
|
1870 |
250000782 |
SCREW-HEX CAP
HexagonalHeadCapScrewM8X45*2
|
|
1900 |
270000762 |
SHIM 1-3MM
Shim1.3mm*3
|
|
2000a |
273000342 |
AIRBOX BASE
AirboxBase*1
|
|
2000b |
273000373 |
AIRBOX COVER
AirboxCover*1
|
|
2000c |
273000359 |
INTAKE TUBE
IntakeHose*1
|
|
2000d |
273000375 |
HOSE CONNECTOR
HoseConnector*1
|
|
2000e |
273000290 |
TUBE
AirSilencerHose*2
|
|
2000f |
219903177 |
NOTICE LABEL
NoticeDecal,AirSilencer*1
|
|
2000g |
708000759 |
STOPPER-RUBBER
RubberStopper*6
|
|
2000h |
250000287 |
SCREW-PT.FLANGE PAN HDTORX.K40 X 16
FlangedTorxScrewK40X16*5
|
|
2300 |
270000950 |
FORMED HOSE
FormedHose*1
|
|
2305 |
273000234 |
BREATHER
Breather*1
|
|
2310 |
293650284 |
CLAMP GEAR
ClampGear*1
|
|
2315 |
293650284 |
CLAMP GEAR
ClampGear*1
|
|
2350 |
273000387 |
HOSE INTAKE
HoseIntake*1
|
|
2370 |
293830197 |
POLYURETHANE HOSE
Hose*2
|
|
2380 |
293750008 |
TIE-RAP 350MM
Tie-Rap350mm*2
|
|
2400 |
293650283 |
CLAMP GEAR
ClampGear*1
|
|
2410 |
293650283 |
CLAMP GEAR
ClampGear*1
|
|
2420 |
273000380 |
INTAKE HOSE
IntakeHose*1
|
|
2430 |
293650283 |
CLAMP GEAR
ClampGear*1
|
|
3000-3000a |
276000335 |
INTERCOOLER
Intercooler.Includes3000TO3000a*1
|
|
3000a |
271001942 |
ANODE ZINC
AnodeZinc*1
|
|
3010 |
273000338 |
INLET HOSE
InletHose*1
|
|
3020 |
293650244 |
TRIDON GEAR CLAMP
TridonGearClamp*1
|
|
3025 |
293650283 |
CLAMP GEAR
ClampGear*1
|
|
3030 |
273000377 |
OUTLET HOSE
OutletHose*1
|
|
3040 |
293650244 |
TRIDON GEAR CLAMP
TridonGearClamp*1
|
|
3045 |
293650283 |
CLAMP GEAR
ClampGear*1
|
|
3070 |
293850094 |
STRAP-TANK FUE
FuelTankStrap*2
|
|
3072 |
293850093 |
STRAP-FUEL TANK
FuelTankStrap*1
|
|
3075 |
293850095 |
STRAP-FUEL TANK
FuelTankStrap*1
|
|
3080 |
293830178 |
PAD-RUBBER
Pad-Rubber*1
|
|
3090 |
293730016 |
DART-BLACK
Dart,Black*2
|
|
3510 |
293750001 |
TIE-RAP 94MM
Tie-Rap94mm*2
|
|
3530 |
414115200 |
TIE-RAP 180MM
Tie-Rap180mm*1
|
|
3540 |
414115200 |
TIE-RAP 180MM
Tie-Rap180mm*1
|
|
