見出番号 |
部品番号 |
部品名 |
数量 |
1000 |
274001648 |
MUFFLER
Muffler*1
|
|
1050 |
278002895 |
SENSOR-LIQUID
Temperature-Sensor*1
|
|
1100 |
274001354 |
PIPE-HEAD
Head-Pipe-Ass'y.-Includes-1100a-to-1100b*1
|
|
1100b |
293700023 |
FITTING-ELBOW
Elbow-Fitting-90°*1
|
|
1200 |
274001417 |
EXHAUST CLAMP
Exhaust-Clamp*1
|
|
1250 |
274001610 |
HOSE
Hose*1
|
|
1260 |
293650281 |
CLAMP GEAR
Clamp-Gear*1
|
|
1265 |
293650281 |
CLAMP GEAR
Clamp-Gear*1
|
|
1500 |
274001479 |
EXHAUST SUPP
Exhaust-Muffler-Support*1
|
|
1510 |
274001358 |
STOPPER
Stopper*2
|
|
1520 |
293830181 |
RUBBER PAD
Rubber-Pad*1
|
|
1525 |
414939500 |
DART-WINDSHIEL 1=1 PAC
Dart*2
|
|
1530 |
293850093 |
STRAP-FUEL TANK
Fuel-Tank-Strap*1
|
|
1540 |
293150043 |
RIVET-POP 3/16
Pop-Rivet-3/16"*2
|
|
1550 |
274001609 |
SUPPORT
Support*1
|
|
1560 |
232581200 |
NUT-STOP ELASTIC DIN.985
Hex.-Elastic-Nut-M8,-Brass*1
|
|
1570 |
293050001 |
WASHER-8MM
Flat-Washer*1
|
|
1750 |
274001612 |
FRONT EXHAUST HOSE
Exhaust-Hose*1
|
|
1760 |
293650283 |
CLAMP GEAR
Clamp-Gear*1
|
|
1770 |
293650282 |
CLAMP GEAR
Clamp-Gear*1
|
|
2000 |
274001514 |
RESONATOR
Resonator*1
|
|
2200 |
293850120 |
STRAP
Strap*1
|
|
2500 |
292001831 |
BRACKET
Bracket*1
|
|
2550 |
293830173 |
PAD-RUBBER
Pad-Rubber*1
|
|
2750 |
274001628 |
MOLDED HOSE
Rear-Exhaust-Hose*1
|
|
2760 |
293650282 |
CLAMP GEAR
Clamp-Gear*1
|
|
2770 |
293650282 |
CLAMP GEAR
Clamp-Gear*1
|
|
3000 |
274001659 |
EXHAUST FITTING
Exhaust-Fitting*1
|
|
3010 |
274001541 |
NUT-77MM
Nut-77mm*1
|
|
3020 |
274001587 |
WASHER
Washer*1
|
|
