見出番号 |
部品番号 |
部品名 |
数量 |
1 |
232581200 |
NUT-STOP ELASTIC DIN.985
Hex.-Elastic-Nut-M8,-Brass-*1
|
|
2 |
234082600 |
WASHER-FLAT DIN.9021B-A2
Flat-Washer-8-mm,-Stainless-*1
|
|
3 |
274001354 |
PIPE-HEAD
Head-Pipe-Ass'y-*1
|
|
4 |
274001358 |
STOPPER
Stopper-*2
|
|
5 |
274001366 |
RH RESONATOR
Resonator-*1
|
|
5a |
293200003 |
SEAL-TRAY
Neoprene-Seal,-Meter-*1
|
|
6 |
274001417 |
EXHAUST CLAMP
Exhaust-Clamp-*1
|
|
7 |
274001458 |
HOSE-EXHAUST
Front-Formed-Exhaust-Hose-*1
|
|
8 |
278002895 |
SENSOR-LIQUID
Temperature-Sensor-*1
|
|
9 |
274001479 |
EXHAUST SUPP
Exhaust-Muffler-Support-*1
|
|
10 |
274001540 |
EXHAUST OULTET
Outlet-Exhaust-*1
|
|
11 |
274001541 |
NUT-77MM
Nut-77mm-*1
|
|
12 |
274001587 |
WASHER
Washer-*1
|
|
13 |
274001589 |
MUFFLER
Muffler-*1
|
|
14 |
274001608 |
HOSE-EXHAUST
Hose-Exhaust-*1
|
|
16 |
274001609 |
SUPPORT
Support-*1
|
|
17 |
274001610 |
HOSE
Hose-*1
|
|
18 |
293050001 |
WASHER-8MM
Flat-Washer-*1
|
|
19 |
293150043 |
RIVET-POP 3/16
Pop-Rivet-3/16"-*4
|
|
20 |
293150123 |
RIVET-POP 3/16
Pop-Rivet-3/16"-*1
|
|
21 |
293650179 |
CLAMP-TRIDON
Tridon-Clamp-*3
|
|
22 |
293650202 |
CLAMP GEAR
Gear-Clamp-*2
|
|
23 |
293650244 |
TRIDON GEAR CLAMP
Tridon-Gear-Clamp-*1
|
|
24 |
293700023 |
FITTING-ELBOW
Elbow-Fitting-90°-*1
|
|
25 |
293830181 |
RUBBER PAD
Rubber-Pad-*1
|
|
27 |
293850093 |
STRAP-FUEL TANK
Strap-*1
|
|
29 |
414939500 |
DART-WINDSHIEL 1=1 PAC
Dart-*2
|
|
