見出番号 |
部品番号 |
部品名 |
数量 |
1-6 |
420894026 |
ENGINE BLOCK ASS Y
EngineBlock(1個)
|
|
2 |
420632010 |
PIN-CENTER
CenterPin8X12(4個)
|
|
3 |
420641317 |
PLUG SCREW
PlugScrewM20X1.5(1個)
|
|
4 |
420641323 |
SCREW
PlugScrewM10X1(1個)
|
|
5 |
420933180 |
CUSHION
Cushion(4個)
|
|
6 |
420933185 |
CUSHION
Cushion(4個)
|
|
7 |
420933140 |
RING HALF
RingHalf(2個)
|
|
8 |
420840508 |
PIN-THREADED
ThreadedPin(1個)
|
|
9 |
420641213 |
TORX FLANGE SCREW
FlangedTorxScrewM8X55(2個)
|
|
10 |
420641258 |
SCREW TORX FLANGE M6 X 35
FlangedTorxScrewM6X35(12個)
|
|
11 |
420940945 |
TORX-REDUCED SHAFT SCREW M9X113
FlangedTorxScrewM9X113(8個)
|
|
12 |
420431820 |
GASKET
Gasket(1個)
|
|
13 |
420911502 |
OIL SUMP
OilSump(1個)
|
|
14 |
420841548 |
FLANGED TORX SCREW M6 X 2
FlangedTorxScrewM6X25(17個)
|
|
15-20 |
420911681 |
PTO COVER
PTOCover(1個)
|
|
16 |
420450165 |
SEAL-OIL
OilSeal(2個)
|
|
17 |
420947500 |
RING DISTANCE
RingDistance(1個)
|
|
18 |
420945693 |
RETAINING RING
RetainingRing(1個)
|
|
19 |
420850220 |
O RING
OilSeal(1個)
|
|
20 |
420945820 |
RETAINING RING
RetainingRing(1個)
|
|
21 |
420450080 |
GASKET
Gasket(1個)
|
|
22 |
420641248 |
FLANGED TORX SCREW M8 X 2
FlangedTorxScrewM8X25(6個)
|
|
23 |
420950142 |
RING-SEALING
SealingRing(1個)
|
|
24 |
420441653 |
FLANGED TORX SCREW M8 X 1
FlangedTorxScrewM8X16(1個)
|
|
25 |
420911770 |
ENGINE BRACKET FRONT INL
FrontEngineBracket,Intake(1個)
|
|
26 |
420911775 |
ENGINE BRACKET FRONT EXH
FrontEngineBracket,Exhaust(1個)
|
|
27 |
420911780 |
ENGINE BRACKET REAR INL
RearEngineBracket,Intake(1個)
|
|
28 |
420911785 |
ENGINE BRACKET REAR EXH
RearEngineBracket,Exhaust(1個)
|
|
29 |
420641208 |
HEX FLANGED SCREW M8 X 45
Hex.FlangedScrewM8X45(12個)
|
|
30 |
420664031 |
KNOCK SENSOR
NoiseSensor(1個)
|
|
31 |
420641188 |
TORX FLANGE SCREW
FlangedTorxScrewM8X35(1個)
|
|
32 |
420686238 |
ENGINE GASKET SET
GasketSet(1個)
|
|
33 |
420090332 |
LONG BLOCK 903
LongBlock(1個)
|
|
