見出番号 |
部品番号 |
部品名 |
数量 |
1 |
420835059 |
IDLE GEAR 31TH
IdleGear,31Teeth(1個)
|
|
2 |
420947394 |
GRADUATED SPACER
Spacer(1個)
|
|
3 |
420440207 |
SCREW TORX FLANGE M6 X 20
FlangedTorxScrewM6X20(1個)
|
|
4 |
420835230 |
WATER PUMP GEAR
WaterPumpGear(1個)
|
|
5 |
420232431 |
NEEDLE PIN
NeedlePin(1個)
|
|
6 |
420827261 |
WASHER-THRUST
ThrustWasher(1個)
|
|
7 |
420931802 |
SEAL-OIL
OilSeal(1個)
|
|
8 |
420820150 |
WATERPUMP SHAFT
WaterpumpShaft(1個)
|
|
9 |
420850946 |
SEAL
Seal(1個)
|
|
10 |
420222880 |
IMPELLER-WATER
WaterImpeller(1個)
|
|
11 |
420822651 |
THERMOSTAT
Thermostat80°(1個)
|
|
12 |
420950893 |
O RING
O-Ring(1個)
|
|
13 |
420922155 |
THERMOSTAT COVER
ThermostatCover(1個)
|
|
14-15 |
420922293 |
WATER PUMP HOUSING
WaterPumpHousing(1個)
|
|
15 |
420431682 |
JOINT ETANCHE *GASKET
Gasket(1個)
|
|
16 |
420840673 |
FLANGED TORX SCREW M6 X 5
FlangedTorxScrewM6X55(2個)
|
|
17 |
404146600 |
WASHER-SEALING
SealingWasher(1個)
|
|
18 |
420840663 |
FLANGED TORX SCREW M6 X 3
FlangedTorxScrewM6X30(3個)
|
|
19 |
278002895 |
SENSOR-LIQUID
TemperatureSensor(1個)
|
|
