見出番号 |
部品番号 |
部品名 |
数量 |
10 |
276000462 |
HOSE_RIDE PLATE LH
HoseRidingPlateLH(1個)
|
|
20 |
293650245 |
NORMA CLAMP
NormaClamp(1個)
|
|
25 |
293650245 |
NORMA CLAMP
NormaClamp(1個)
|
|
200 |
276000487 |
FORMED HOSE
HoseRidingPlateRH(1個)
|
|
210 |
293650245 |
NORMA CLAMP
NormaClamp(1個)
|
|
215 |
293650245 |
NORMA CLAMP
NormaClamp(1個)
|
|
510 |
293650019 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
515 |
293650115 |
CLAMP-SPRING
SpringClamp(1個)
|
|
520 |
293750001 |
TIE-RAP 94MM
Tie-Rap94mm(1個)
|
|
530 |
293750001 |
TIE-RAP 94MM
Tie-Rap94mm(1個)
|
|
700 |
276000419 |
COOLANT TANK
CoolantTank(1個)
|
|
720 |
276000100 |
PRESSURE CAP ASSY
PressureCap(1個)
|
|
810 |
293650170 |
HOSE CLAMP
TridonGearClamp(1個)
|
|
815 |
293650170 |
HOSE CLAMP
TridonGearClamp(1個)
|
|
835 |
414115200 |
TIE-RAP 180MM
Tie-Rap180mm(1個)
|
|
860 |
293750001 |
TIE-RAP 94MM
Tie-Rap94mm(1個)
|
|
1010 |
293650051 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
1015 |
293650051 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
1060 |
293650051 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
1065 |
293650051 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
1090 |
293710131 |
FITTING-T
T-Fitting.PackageX(1個)
|
|
1210 |
293650172 |
HOSE CLAMP
TridonGearClamp(1個)
|
|
1215 |
293650172 |
HOSE CLAMP
TridonGearClamp(1個)
|
|
1260 |
293650172 |
HOSE CLAMP
TridonGearClamp(1個)
|
|
1265 |
293650172 |
HOSE CLAMP
TridonGearClamp(1個)
|
|
1290 |
293710132 |
FITTING-T
T-Fitting(1個)
|
|
2250 |
276000457 |
FORMED HOSE
Hose,IntercoolerInlet(1個)
|
|
2260 |
293650051 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
2265 |
293650051 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
2270 |
276000461 |
FORMED HOSE
Hose,IntercoolerOutlet(1個)
|
|
2280 |
293650051 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
2285 |
293650051 |
CLAMP-TRIDON
TridonGearClamp(1個)
|
|
2340 |
293720029 |
GROMMET
Grommet(1個)
|
|
2345 |
414518500 |
CONNECTOR-MALE
MaleConnector(1個)
|
|
2355 |
293650170 |
HOSE CLAMP
TridonGearClamp(1個)
|
|
2360 |
293650025 |
CLAMP-OETIKER
OetikerGearClamp(1個)
|
|
4000 |
293750008 |
TIE-RAP 350MM
Tie-Rap350mm(1個)
|
|
4020 |
414115200 |
TIE-RAP 180MM
Tie-Rap180mm(1個)
|
|
4100 |
414115200 |
TIE-RAP 180MM
Tie-Rap180mm(1個)
|
|
