見出番号 |
部品番号 |
部品名 |
数量 |
1000 |
274001685 |
MUFFLER
Muffler(1個)
|
|
1050 |
278002895 |
SENSOR-LIQUID
TemperatureSensor(1個)
|
|
1250 |
274001692 |
BOOT
Boot(1個)
|
|
1260 |
293650202 |
CLAMP GEAR
GearClamp(1個)
|
|
1265 |
293650299 |
CLAMP_GEAR
GearClamp(1個)
|
|
1500 |
293450365 |
MUFFLER SUPPORT
MufflerSupport(1個)
|
|
1510 |
274001721 |
Stopper(2個)
|
|
1520 |
293830153 |
PAD-RUBBER
PadRubber(1個)
|
|
1525 |
414939500 |
DART-WINDSHIEL 1=1 PAC
Dart(2個)
|
|
1530 |
293850120 |
STRAP
Strap(1個)
|
|
1540 |
293150043 |
RIVET-POP 3/16
PopRivet3/16"(4個)
|
|
1750 |
274001709 |
FORMED HOSE
FrontExhaustHose(1個)
|
|
1760 |
293650244 |
TRIDON GEAR CLAMP
TridonGearClamp(1個)
|
|
1770 |
293650244 |
TRIDON GEAR CLAMP
TridonGearClamp(1個)
|
|
2000 |
274001514 |
RESONATOR
Resonator(1個)
|
|
2200 |
293850120 |
STRAP
Strap(1個)
|
|
2500 |
292002297 |
HOOK_RETAINING
HookRetaining(1個)
|
|
2550 |
293830173 |
PAD-RUBBER
Pad-Rubber(1個)
|
|
2750 |
274001628 |
MOLDED HOSE
ExhaustHoseRear(1個)
|
|
2760 |
293650244 |
TRIDON GEAR CLAMP
TridonGearClamp(1個)
|
|
2770 |
293650244 |
TRIDON GEAR CLAMP
TridonGearClamp(1個)
|
|
3000 |
274001659 |
EXHAUST FITTING
ExhaustFitting(1個)
|
|
3010 |
274001541 |
NUT-77MM
Nut-77mm(1個)
|
|
3020 |
274001587 |
WASHER
Washer(1個)
|
|
