見出番号 |
部品番号 |
部品名 |
数量 |
1000 |
274001685 |
MUFFLER
Muffler×1個
|
|
1050 |
278002895 |
SENSOR-LIQUID
Temperature-Sensor×1個
|
|
1250 |
274001692 |
BOOT
Boot×1個
|
|
1260 |
293650202 |
CLAMP GEAR
Gear-Clamp×1個
|
|
1265 |
293650299 |
CLAMP_GEAR
Gear-Clamp×1個
|
|
1500 |
293450390 |
Muffler-Support×1個
|
|
1510 |
274001721 |
Stopper×2個
|
|
1520 |
293830209 |
PAD RUBBER
Rubber-Pad×1個
|
|
1525 |
414939500 |
DART-WINDSHIEL 1=1 PAC
Dart×2個
|
|
1530 |
293850120 |
STRAP
Strap×1個
|
|
1540 |
211000023 |
SCREW-PLASTITE HEX.WR.HD.UNSL
Hex.-Screw-10-14-X-7/8”×4個
|
|
1750 |
274001709 |
FORMED HOSE
Front-Exhaust-Hose×1個
|
|
1760 |
293650244 |
TRIDON GEAR CLAMP
Tridon-Gear-Clamp×1個
|
|
1770 |
293650244 |
TRIDON GEAR CLAMP
Tridon-Gear-Clamp×1個
|
|
2000 |
274001722 |
RESONATOR
Resonator×1個
|
|
2200 |
293850120 |
STRAP
Strap×1個
|
|
2210 |
293850120 |
STRAP
Strap×1個
|
|
2500 |
292001831 |
BRACKET
Bracket×1個
|
|
2550 |
293830173 |
PAD-RUBBER
Pad-Rubber×1個
|
|
2750 |
274001617 |
FORMED HOSE
Rear-Exhaust-Hose×1個
|
|
2760 |
293650244 |
TRIDON GEAR CLAMP
Tridon-Gear-Clamp×1個
|
|
2770 |
293650244 |
TRIDON GEAR CLAMP
Tridon-Gear-Clamp×1個
|
|
