見出番号 |
部品番号 |
部品名 |
数量 |
1 |
420911052 |
IGNITION COVER
Cover×1個
|
|
2 |
420431640 |
GASKET
Gasket×1個
|
|
3 |
420840663 |
FLANGED TORX SCREW M6 X 3
Flanged-Torx-Screw-M6-X-30×14個
|
|
4 |
420966570 |
CRANK POSITION SENSOR
Crankshaft-Position-Sensor-Ass'y.-Includes-4-to-5×1個
|
|
5 |
420431580 |
O RING
O-Ring×1個
|
|
6 |
420641048 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M6-X-16×1個
|
|
7 |
420296908 |
PLATE-STATOR
Stator-Plate-420W×1個
|
|
8 |
420241956 |
SCREW-ALLEN M6X40
Allen-Screw-M6-X-40×3個
|
|
9 |
420685702 |
FLYWHEEL
Flywheel-420W×1個
|
|
10 |
420627270 |
SHIM
Shim×1個
|
|
11 |
420241549 |
SCREW-ALLEN
Socket-Head-Screw-M16-X-35×1個
|
|
12 |
420440854 |
SCREW-TORX FLANGE
Flanged-Torx-Screw-M8-X-16×3個
|
|
13 |
420659113 |
SPRAG CLUTCH
Sprag-Clutch×1個
|
|
14 |
420659263 |
SPRAG CLUTCH HOUSING
Sparg-Clutch-Housing×1個
|
|
15 |
420434238 |
FREE WHEEL GEAR
Free-Wheel-Gear,-64-Teeth×1個
|
|
16 |
420229475 |
PIN-NEEDLE
Needle-Pin×1個
|
|
17 |
420634741 |
DOUBLE GEAR
Double-Gear×1個
|
|
18 |
420893830 |
STARTER ASSY
Starter-Ass'y×1個
|
|
19 |
420250145 |
O RING
O-Ring×2個
|
|
20 |
420840663 |
FLANGED TORX SCREW M6 X 3
Flanged-Torx-Screw-M6-X-30×2個
|
|
21 |
420866714 |
TIE RAP
Tie-Rap×1個
|
|
22 |
420881145 |
CARBON BRUSH SET
Carbon-Brush-Set×1個
|
|
