見出番号 |
部品番号 |
部品名 |
数量 |
1 |
420893521 |
Cylinder-Block.-Includes-1-to-10×1個
|
|
2 |
420632010 |
PIN-CENTER
Center-Pin-8-X-12×4個
|
|
3 |
420956772 |
OIL SPRAY NOZZLE
Oil-Spray-Nozzle×3個
|
|
4 |
420250015 |
ALUMINUM WASHER
Washer,-Copper×1個
|
|
5 |
420841923 |
PLUG SCREW M12
Plug-Screw-M12×1個
|
|
6 |
420641120 |
TORX-RED SHAFT SCREW M11X147
Torx-Flanged-Screw-M10-X-82×8個
|
|
7 |
420641208 |
HEX FLANGED SCREW M8 X 45
Hex.-Flanged-Screw-M8-X-45×15個
|
|
8 |
420641317 |
PLUG SCREW
Plug-Screw-M20-X-1.5×2個
|
|
9 |
420232482 |
BUSHING-NEEDLE
Needle-Bushing×1個
|
|
10 |
420240692 |
Allen-Screw-M5-X-10×1個
|
|
11 |
420933456 |
PLAIN BEARING HALF
Plain-Half-Bearing×4個
|
|
12 |
420933466 |
PLAIN BEARING HALF
Plain-Half-Bearing×4個
|
|
13 |
420933475 |
RING HALF
Half-Ring×2個
|
|
14 |
420933442 |
PLAIN BEARING HALF
Plain-Bearing-Half×4個
|
|
15 |
420933470 |
RING HALF
Half-Ring×2個
|
|
16 |
420641171 |
PLUG SCREW M30
Plug-Screw-M30-X-1.5.-Includes-16-to-17×8個
|
|
17 |
420631300 |
O-RING
O-Ring×1個
|
|
18 |
420249073 |
GROOVED PIN
Grooved-Pin×2個
|
|
19 |
420430405 |
O-RING
O-Ring×1個
|
|
20 |
420660110 |
PLUG COVER
Plug-Cover×1個
|
|
21 |
420811794 |
FRONT ENGINE BRACKET
Front-Engine-Bracket×1個
|
|
22 |
420641188 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-35×4個
|
|
23 |
420811788 |
ENGINE BRACKET PTO. EXHAUST
Engine-Bracket-PTO,-Exhaust×1個
|
|
24 |
420641188 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-35×2個
|
|
25 |
420641213 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-55×2個
|
|
26 |
420811784 |
ENGINE BRACKET PTO. INTAKE
Engine-Bracket-PTO,-Exhaust×1個
|
|
27 |
420641213 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-55×4個
|
|
28 |
420851740 |
RETAINING PLATE
Retaining-Plate×1個
|
|
29 |
420660290 |
HOSE BRACKET
Hose-Bracket×1個
|
|
30 |
420847971 |
SPACER
Spacer×2個
|
|
31 |
420660090 |
RUBBER BRACKET
Rubber-Bracket×2個
|
|
32 |
420827968 |
WASHER M6
Flat-Washer-M6×2個
|
|
33 |
420641258 |
SCREW TORX FLANGE M6 X 35
Flanged-Torx-Screw-M6-X-35×2個
|
|
34 |
420664031 |
KNOCK SENSOR
Noise-Sensor×1個
|
|
35 |
420641188 |
TORX FLANGE SCREW
Flanged-Torx-Screw-M8-X-35×1個
|
|
36 |
420889777 |
Gasket-Set×1個
|
|
37 |
420160333 |
ENGINE BLOCK 1603
Engine-Long-Block-1603.-Model-Without-iDF-Gearbox×1個
|
|
37 |
420160314 |
Engine-Long-Block-1603.-Model-With-iDF-Gearbox×1個
|
|
